5. Operation Controls and Functions
Front Panel
1 2 3
Name
No.
48V LED 1/2
1
Audio IN 1/2
2
port
IN 1/2
3 48V button &
backlit LED
Audio OUT
4
1/2 port
4
5
6
7
8
Function Description
48V phantom power
power of the MIC audio input channel 1/2 is turned
on, the corresponding
Balanced/unbalanced XLR analog audio input port
1/2, connected to MIC/LINE analog audio source
devices.
Press the button to turn on the 48V phantom power
of the MIC audio input channel 1/2, then the
corresponding backlit LED is on.
Balanced/unbalanced XLR analog audio output
port 1/2, connected to analog audio source devices.
4 / 6
9
10
LEDs. When the 48V phantom
48V LED is on.
