Installation Guide | iC7 Series Air-cooled LCL Filter OF7Z3
1
Figure 2: Installing the L Filter
1 The mounting holes at the back
3 Bottom mounting bracket
3. Install the integration unit of the AFE module into the cabinet.
Figure 3: Installing the Integration Unit of the AFE Module
1 The mounting holes at the back
4.
Push and slide the LC Filter into the cabinet, on top of the L Filter.
Danfoss Drives Oy © 2024.11
1
1 1
1 1
2 2
2 2
2
3
2 The mounting holes in the front
2 2 2
2 2
2 The mounting holes in the front
AN447722806364en-000201 / 172K1109B |
Mechanical Installation
1 1
3
