Installation Guide | iC7 Series Air-cooled LCL Filter OF7Z3
BURN HAZARD
The filter is hot during operation.
Do not install the filter on a combustible surface.

Do not touch the filter when hot.

Only qualified personnel are allowed to perform the installation described in this guide.
Follow the instructions in this guide and relevant local regulations.
Also read the instructions and safety information in the iC7 Series Air-cooled and Liquid-cooled System Modules Installation Safety Guide.
Installation Requirements
2.2
The products described in this guide have the protection rating IP00/UL Open Type. Install the products in an enclosure that has a
correct level of protection against the ambient conditions in the installation area. Make sure that the enclosure gives protection against
water, humidity, dust, and other contaminations.
The enclosure must also be sufficiently strong for the weight of the filter components and other devices.
The protection rating of the enclosure must be at least IP21/UL Type 1. When preparing the installation, obey the local regulations.
Installing the LCL Filter into the Cabinet
2.3
This is the recommended installation procedure for iC7 Series Air-cooled LCL Filters and AFE modules with an integration unit.
The wider variant LCL11W can be installed with the AFE module in a 600 mm wide cabinet. It is not possible to install LCL11W with the
INU and AFE modules in an 800 mm wide cabinet.
See the installation dimensions in
1.
Install mounting brackets to the cabinet.
Mounting brackets are not included in the delivery.
2.
Install the L Filter into the cabinet.
a.
Mount the L Filter to the back wall of the cabinet.
b.
Mount the front of the L Filter to a mounting bracket.
c. Optionally, the L Filter can also be mounted from the bottom with the bottom mounting bracket.
The bottom mounting bracket and mounting screws for it are included in the delivery.
