A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
GM Silverado/Sierra
NOTE: Not compatible with drop in liners with integrated storage pockets.
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST
Designed and manufactured by AMP Research
Patent Protected. Please see our product site for applicable patents. www.realtruck.com/b/amp-research/
© 2024 AMP Research • Three-year limited warranty. • Professional installation is recommended.
www.realtruck.com
YEAR
2019 - 2023
• Made in Mexico
®
1/7
PART #
74841-00A (Silver)
INSTALLATION TIME
SKILL LEVEL
1
TOOLS REQUIRED
Phillips screw driver
Torx T-20 driver
Torx T-25 driver
Power drill
1/8" drill bit
21/64" drill bit
Center punch
Supplied templates
Soapy Water
Masking Tape
WARRANTY
3-Year Limited Warranty
74841-01A (Black)
1 Hour
4
2 3
1= Easy
IM 74841 rev 04.23.24
Advertisement
Related Manuals for REALTRUCK AMP RESERCH BedXTender HD MAX
Summary of Contents for REALTRUCK AMP RESERCH BedXTender HD MAX
- Page 1 Verify all parts against parts list. 3-Year Limited Warranty Read and understand instructions completely before attempting assembly and installation. REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST Designed and manufactured by AMP Research • Made in Mexico ®...
- Page 2 Silver: (Small) (Small Black) Black: (Small) (Small Black with LOGO) Silver: (Deep) (Large/Deep Black) Black: (Deep) (Large/Deep Black with LOGO) Silver: (Large) (Large/Deep Silver) Black: (Large) (Large/Deep Silver with LOGO) Pivot Upright Assembly Center Tube www.realtruck.com IM 74841 rev 04.23.24...
- Page 3 PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION Assemble U-Nuts on to bracket plates in the orientation shown. M8 Bolt M8 U-Nut Driver Passenger Bracket Nut Plate Remove the tail lights using T20 torx driver. Carefully pull back to remove tail lights. www.realtruck.com IM 74841 rev 04.23.24...
- Page 4 (indicated). Pre drill hole with 1/8” drill bit, losen upper mounting hole and rotate bracket away from hole and open hole using a 21/64” drill bit. Remove burs, apply primer to edge of holes, and allow primer to dry. Install brackets. Reinstall Tail Lights. www.realtruck.com IM 74841 rev 04.23.24...
- Page 5 NOTE: The inside of the upright is stepped to fit NOTE: Do not over tighten as this may strip out. correctly around the small and large diameter Fastener will reach a noticable stopping point. tubes. www.realtruck.com IM 74841 rev 04.23.24...
- Page 6 Adjust Strap Buckles to lock into the tailgate when BEDXTENDER is deployed. Your assembly is now complete. NOTE: Ensure that buckles are properly inserted into latches by pulling on the straps after both buckles have been inserted. www.realtruck.com IM 74841 rev 04.23.24...
- Page 7 The straps will be secured on the bottom clips when Bed Extender is flipped in, this will leave the top clips free to use to hold grocery bags if needed. Closing tailgate to keep cargo secured in bed. www.realtruck.com IM 74841 rev 04.23.24...
- Page 8 • Faster and easier access to customer service and tech support in the unlikely event you need warranty or product support. • Registration helps us keep you up to date on product information and offers. To view other Realtruck products that may be offered for your vehicle. Please visit: www.realtruck.com Rev 03.26.24...
-
Page 9: Limited Warranty
LIMITED WARRANTY REALTRUCK warrants product to be free from defects in material and workmanship, for terms specified below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replace- ment of any item found by the factory to be defective within the time period specified.
