REALTRUCK RETRAX EQ Installation Sheet

Ram 1500 rambox 2019-24
Hide thumbs

Advertisement

Quick Links

Download this manual
PLEASE READ INSTRUCTIONS CAREFULLY
BEFORE STARTING THE INSTALLATION
1
Physically install the Retrax EQ cover on the truck
and make all necessary wired connections.
Refer to the next page for full EQ installation instructions.
3
Open the installer app and follow prompts
to configure the CABIN module.
RealTruck Retrax • 917 S. 46th St., Grand Forks, ND 58201 • 800-206-4070 © RealTruck Group, Inc., 2025
the COVER module.
iOS
Android
Ram 1500 RamBox 2019-24
EQ QUICK START
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 800-206-4070 Mon - Fri, 8:30 a.m. - 5:00 p.m. CST
or email retrax@retrax.com
2
Physically install the cabin module inside the truck.
4
In the installer app, follow
the prompts to configure
Cabin Module
Setup a new system
Edit configuration
Update firmware
Cover Module
Pair to cabin module
Update firmware
Installation Guides
5
Pair accessory controls
such as keypad and
phone (optional). Refer to
the instructions shipped with
accessories.
1
2
3
4
5
6
7
8
9
0
4000-287 IR-REQ-01 Rev. 3-6-25
