A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
RAM DT
(Not compatible with Ram Box or MultiFunction Tailgate applications)
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting
assembly and installation.
REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST
Designed and manufactured by AMP Research
Patent Protected. Please see our product site for applicable patents. www.realtruck.com/b/amp-research/
© 2024 AMP Research • Three-year limited warranty. • Professional installation is recommended.
www.realtruck.com
YEAR
2019 - 2024
• Made in Mexico
®
1/6
PART #
74840-00A (Silver)
INSTALLATION TIME
SKILL LEVEL
1
TOOLS REQUIRED
Phillips screw driver
Torx T-25 driver
Power drill
5/32" drill bit
Center punch
Supplied templates
Soapy Water
WARRANTY
3-Year Limited Warranty
74840-01A(Black)
1 Hour
2 3
4
1= Easy
rev 04.23.24
