- Page 1 INSTALLATION INSTRUCTIONS CUSTOMER SERVICE Phone: 877-878-9336 • 8:00 am - 5:00 pm Mon - Fri CT Email: customersupport@truxedo.com RealTruck TruXedo 2209 Kellen Gross Dr., Yankton SD 57078 Rev. 11-28-23 ©RealTruck Group, Inc., 2024...
-
Page 2: Tools Required
OWNER'S MANUAL Damaged or missing parts? Call 877-878-9336 Mon - Fri 8 am - 5 pm CT Parts will be shipped to you factory direct. Do not return kit to place of purchase. READ INSTRUCTIONS - Failure to assemble cover properly will void warranty. - Page 3 Install the six clamp brackets (D) to the truck box. Leave Attach the end plug seals (G & H) to the front ends of the driver and passenger rails (A & B). hardware loose at this time. Align the profile of each seal to the profile of the end caps.
- Page 4 Many truck tailgates, when closed, have corner gaps that allow moisture to enter the truck bed. Apply the end plug seals (G and H) to the rear side rail end plugs and truck bed corners to block moisture from entering the truck bed at the tailgate. End Plug Seal (H) End Plug Seal (G) Driver Side Shown...
-
Page 5: Opening The Cover
Once the cover is closed, grab the fabric flap and evenly pull it With both sides of the hook and loop engaged, use the palms over the hook track engaging the loop to the hook. of your hand to firmly push the loop strip into the hook track. Do this to both driver and passenger sides. - Page 6 WARRANTY DURATION TruXedo®, Inc. (“TruXedo”) offers a LIFETIME warranty on Lo Pro, Deuce and Pro X15. Warranty is limited to original purchaser of truck bed cover and is nontransferable. The warranty registration must be on file and/or proof of original purchase (detailed and dated receipt) required for warranty service.
-
Page 7: Troubleshooting Tips
Covers that are used frequently or are subject to vibrations and impacts from rough roadways may require adjustment. • WHY IS THERE A HOLE PUNCHED AT THE REAR OF THE PASSENGER SIDE RAIL OF THE TRUXEDO LO PRO, DEUCE AND PRO X15 BUT NO LATCH? All side rails are punched identically to keep them uniform, to ensure manufacturing efficiency and to reduce tooling costs. - Page 8 3" Replacement Parts ______ Replacement Cover 11 ______ Aluminum Cross Tubes 17 ______ Rail, Passenger's Side ______ Black Front Header 12 1704187 Header Stop 18 ______ Rail, Driver's Side 13 1115356 Tension Control Housing & 19 1705727 Flat Spring, 5/8" x 3 7/8" ______ Header Seal Front 20 1704213 Latch Assembled...
