TOOLS REQUIRED
•
Scissors or utility knife
•
Isopropyl alcohol
•
1/2" Wrench or socket
•
Phillips screwdriver
•
7/16" Wrench
•
13mm Wrench
or socket
PARTS INCLUDED IN YOUR KIT
1x Hard fold cover
A
1x Driver side rail
B
1x Passenger side rail
C
1x Bulkhead seal
D
6x Clamp assembly
E
1x Driver front truck bracket
F
1x Passenger front truck bracket
G
1x Driver rear truck bracket
H
1x Passenger rear truck bracket
I
2x Cover retainer clamps
J
2x Rear truck bracket mounting nuts 1/4-20
K
2x Front truck bracket mounting bolts M8 x 1.25 x 20
L
4x Step spacers
M
2x Rubber spacers
N
2x Foam pad bulkhead seals
O
2x Buckle ends
P
2x Gaskets
Q
4x Screws
R
4x Nutserts
S
2x Drain tubes
T
3x D-shaped cab bumpers
U
RealTruck BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 818-365-9000 ©RealTruck Group, Inc., 2024
NOTE: It is important that all areas
where the bed cover mounts are clean
and free of debris prior to installing.
A
B
D
I
2019-2023 FORD RANGER
BAKFLIP
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 818-365-9000 Mon - Fri 8:30 am - 7:00 pm EST
or email support@bakindustries.com
C
Q
R
P
S
D
J
E
G
F
H
E
F
K
J
O
T
U
M
N
L
K
O
I
G
L
M
P
Q
T
Part# 318S0072 Rev. 9-24-24
H
N
R
S
U
