- Page 1 Programmable DC Electronic Load PEL-2000A Series QUICK START GUIDE GW INSTEK PART NO. 82EL-2KA00M01 ISO-9001 CERTIFIED MANUFACTURER www.valuetronics.com...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.
-
Page 3: Afety Instructions
AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument. - Page 4 Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...
-
Page 5: Etting Started
The PEL-2000A series support four operation modes: constant current (CC), constant voltage (CV and CV+CC), constant resistance (CR) and constant power (CP). Constant current and constant resistance mode can operate in either static or dynamic mode. - Page 6 Load Module Line Up The 4 different load module models each differ in the amount of current, voltage and power and the number of channels that the load module can accommodate. For detailed specifications, please see the user manual. Load Module Channels Power Current Voltage...
- Page 7 • Supports frame link connections, with up to 4 slave units • Color LCD display • 120 different sets of programmable sequences • Accurate load simulation using Sequences • 4 panel setups • USB flash drive support. • Interface • RS-232C •...
- Page 8 Package Contents and Accessories Standard Accessories Item Description Power Cable Mains power cable (region dependent) CD ROM Contains PEL-2000A Series Electronic DC Load User Manual, Programming Manual and USB Driver GTL-120 Load cables 2X red, 2X black (per load module) GTL-121...
-
Page 9: Display Overview - Mainframe
Front Panel - Mainframe PEL-2002A DC Electronic Load LOCAL UTILITY CHAN FUNC FILE HELP PRESET SHIFT CAL. LOCK ON / CLEAR ENTER LOAD Description LCD display Function keys System keys Number pad USB input Selector knob Operation keys Power Display Overview - Mainframe Alarm *CH1 A Value... -
Page 10: Rear Panel
Rear Panel PEL-2004A GPIB GO / NG OUTPUT RS232C SER. NO. LB FRAME CONT REPLACE FUSE AS SPECIFIED FUSE RATING 115V T 3.15A 180 VA MAX 250V 230V 50/60 Hz WARNING CH CONT 8 CH CONT 7 CH CONT 6 CH CONT 5 CH CONT 4 CH CONT 3... - Page 11 Front Panel - Load Module DC Electronic Load L 20A / 80V , 100W PEL-2020A 20A / 80V , 100W STATIC/ R / L DYNA. DISPLAY SHORT LOAD V sense V sense 80V DC 80V DC 80V DC 80V DC Description LED display R/L or A/B key...
-
Page 12: First Time Use Instructions
First Time Use Instructions Use the following procedures when first using the PEL-2000A to power up the instrument, restore the factory default settings and check the firmware version. Lastly, the Conventions section will introduce you to the basic operating conventions used throughout the user manual. - Page 13 Wait a short time for the settings to be recalled. Updating the Firmware The PEL-2000A firmware can be easily updated using a USB memory stick. For the latest firmware please see your local GW Instek distributor or download the latest firmware from www.gwinstek.com. View Firmware Version UTILITY...
- Page 14 Firmware update Press FILE Press Media [F1] repeatedly until the Media USB menu appears. Press the File Utility [F5] soft-key. Select the *.UPG upgrade file using the scroll wheel and press Select[F1] twice. Once to select the file and once to confirm. Wait for the update to finish.
- Page 15 PEL-2002A DC Electronic Load DC Electronic Load L 20A / 80V , 100W PEL-2040A 70A / 80V , 350W 20A / 80V , 100W Soft-menu Alarm *CH1 A Value 80.00 V B Value 80.00 V keys Curr Limit 40.00 A SPEC Slow main...
- Page 16 knob to select a channel to edit. Press the selector knob or the ENTER key to confirm the selection. Use the scroll wheel to move the cursor to the desired parameter. A scroll bar is shown when there are additional parameters off-screen.
- Page 17 Load Module Parameter Input The front panel keys on a load module can be used to edit the CC/CV/CR/CP setting value* of a selected channel independently to the mainframe. DC Electronic Load 20A / 80V , 100W PEL-2020A 20A / 80V , 100W Static/ Dynamic mode...
- Page 18 PECIFICATIONS The following are the basic specifications for the PEL- 2000A series. For detailed specifications, please see the user manual. PEL-2020A Model PEL-2020A (100Wx2) RANGE High CURRENT 0~2A 0~20A VOLTAGE 1~80V MIN.OP. 0.4V at 2A 0.8V at 20A VOLTAGE 0.2V at 1A 0.4V at 10A CC OP.
- Page 19 CR OP. Range 0.3Ω ~1.2kΩ 0.0375Ω ~150Ω (30W/16V) (250W/16V) 15Ω ~60kΩ 1.875Ω ~7.5kΩ (30W/80V) (250W/80V) CR Setting Range 0.3Ω ~1.2kΩ 0.0375Ω ~150Ω (30W/16V) (250W/16V) 15Ω~60kΩ 1.875Ω ~7.5kΩ (30W/80V) (250W/80V) CV+CC OP. 1~80V Range CV+CC Set. Range 0~81.6V CP OP. Range 1~30W 1~25W 1~250W...
-
Page 20: Ec Declaration Of Conformity
EC Declaration of Conformity GOOD WILL INSTRUMENT CO., LTD. No.7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan GOOD WILL INSTRUMENT (SUZHOU) CO., LTD. No. 69, Lushan Road, Suzhou New District Jiangsu, China declares that the below mentioned product PEL-2002, PEL-2020A, PEL-2030, PEL-2030A, PEL-2040, PEL- 2040A, PEL-2041A, PEL-2041A. - Page 21 www.valuetronics.com...
