ACE SOFTWARE OPERATION
EXITING THE SOFTWARE
To exit the software, click File icon on the upper right tab and then
click Close ACE.
DESCRIPTION OF THE ANALYSIS WINDOW
Click Proceed to Analysis in the ADAQ4380-4, ADAQ4370-4,
or ADAQ4381-4 chip view window to open the ADAQ4380-4,
ADAQ4370-4, or ADAQ4381-4 analysis view window, as shown
in Figure 19. The ADAQ4380-4, ADAQ4370-4, or ADAQ4381-4
analysis view window contains the Waveform (see
Histogram (see Figure 22), FFT (see
25), and DNL (see Figure 26) tabs.
In the Device Settings section, click the SDO Mode drop-down
list and select four_wire. Click Run Once to update the register
settings.
CAPTURE Pane
The CAPTURE pane contains the capture settings. These settings
reflect onto the registers automatically before data capture.
In the General Capture Settings section, the Sampling Frequen-
cy (ksps) or Throughput (ksps) field allows the user to set the
throughput rate of the μModule. The ADAQ4380-4, ADAQ4370-4,
or ADAQ4381-4 has a maximum throughput rate of 4/2 MSPS.
By default, the throughput rate is set to 2 MSPS since the SDO
Mode in the Device Settings section is in Two_wire mode. To
change that, click the drop-down list and select four_wire to enable
maximum throughput rate.
In the General Capture Settings section, the Sample Count
drop-down list allows the user to select the number of samples per
capture.
The ADAQ4380-4, ADAQ4370-4, and ADAQ4381-4 have on-chip
oversampling features. In the Device Settings section, click the
Over Sampling Mode drop-down list to select between Normal
Average and Rolling Average oversampling. Click the Over Sam-
pling Ratio drop-down list to enable device oversampling. The
device oversampling section can be set between 2× and 8× for
rolling average oversampling, and between 2× and 32× for nor-
mal average oversampling. For the detailed explanation on the
device on-chip oversampling feature, refer to the ADAQ4380-4,
ADAQ4370-4, or ADAQ4381-4 data sheet.
In the CAPTURE pane, click Run Once to start a data capture
of the samples at the sample rate specified in the Sample Count
drop-down list. These samples are stored on the FPGA device and
are only transferred to the PC when the sample frame is complete.
In the CAPTURE pane, click Run Continuously to start a data
capture that gathers samples continuously with one batch of data at
a time, which runs the Run Once operation continuously.
