User Manual
Universal Smart Wi-Fi Thermostat
This manual covers the following thermostat model:
8205
Up to 3 Heat / 2 Cool Heat Pump
Up to 2 Heat / 2 Cool Conventional
See Wi-Fi Setup Guide for Wi-Fi Setup Instructions
Read all instructions before proceeding.
Store this manual for future reference
8205-110-01
Advertisement
Table of Contents
Related Manuals for Braeburn BlueLink 8205
Summary of Contents for Braeburn BlueLink 8205
- Page 1 ® User Manual Universal Smart Wi-Fi Thermostat This manual covers the following thermostat model: 8205 Up to 3 Heat / 2 Cool Heat Pump Up to 2 Heat / 2 Cool Conventional See Wi-Fi Setup Guide for Wi-Fi Setup Instructions Read all instructions before proceeding.
-
Page 2: Table Of Contents
Contents 1 About Your Thermostat 4 Operating Your Thermostat Quick Reference............4 Setting the System Control Mode ......17 Setting the Fan Control Mode .......18 2 User Settings Temperature Adjustment ........19 Accessing User Settings ........... 8 Program Event Indicators ........19 Table of User Settings ..........9 System Status and Maintenance Indicators ..20 Resetting Service Reminders ........9 Setting the Time and Day ......... -
Page 3: Regulatory Statements
Regulatory Statements This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 4: About Your Thermostat
1 About Your Thermostat User Manual... - Page 5 Thermostat SYSTEM Button ....Selects the system you want to control PROG Button ......Enters programming mode or hold for 3 seconds to enter SpeedSet mode ® BACK Button* ......Secondary function of the PROG button - Moves to previous setting HOLD Button ......
- Page 6 1 About Your Thermostat User Manual...
-
Page 7: Thermostat Display
Thermostat Display Room Temperature ......Displays the current room temperature Set Temperature ......... Displays the current setpoint temperature Override Indicator ........ Indicates that the current program schedule has been temporarily overridden Time of Day .......... Displays the current time of day Message Center ........ -
Page 8: User Settings
2 User Settings User Settings allow you set the current time of day as well as customize various thermostat features. To Enter User Settings Menu 1. Press and release the MENU button 2. Use the or buttons to select OPTIONS SET 3. -
Page 9: Table Of User Settings
Table of User Settings NOTE: Some user settings may not be available, depending on how the thermostat was configured during installation. No. User Setting Displayed Default Available Description of Setting Settings Available Settings Select to keep message displayed RESET / Reset FILTER FILTER Select to remove message and reset timer... -
Page 10: Service Filter Reminder
Table of User Settings (cont.) No. User Setting Displayed Default Available Description of Setting Settings Available Settings Service filter timer is disabled FILTER Service Filter Timer 30, 60, 90, Select number of days for service filter timer 120, 180, 365 Select the number of days before receiving a reminder to change your system filter (if applicable). -
Page 11: Resetting Thermostat
Table of User Settings (cont.) No. User Setting Displayed Default Available Description of Setting Settings Available Settings Reset disabled - no changes made RESET User Reset Reset enabled - resets thermostat Selecting YES will reset all user settings, program and current time. Thermostat lock code and Installer Settings will not be affected. NOTE: This reset will not affect the lock code, wireless connection of the thermostat and/or any connected remote sensors. -
Page 12: Setting Your Program Schedule
3 Setting Your Program Schedule Tips Before Setting Your Program Schedule • Make sure your current time and day of the week are set correctly. • Make sure the AM and PM indicators are correct. • Various installer settings such as auto changeover mode and temperature adjustment limits may affect your programming flexibility. -
Page 13: Default Energy Saving Programs
Default Energy Saving Programs This thermostat comes pre-programmed with a default energy saving program. The following tables outline the pre-programmed times and temperatures for heating and cooling in each of your 4 daily events (2 events if configured for commercial mode). If you wish to use these settings, then no further programming is necessary: 7 Day Programming 5-2 Day Programming Factory Settings... -
Page 14: Programming A 7 Day Schedule
Setting a 7-Day program – All 7 Days at Once (SpeedSet ® (7-day programming mode only) NOTE: Setting all 7 days at once will copy over any previously programmed individual days. Available Daily Events MORN, DAY, EVE, NITE 1. Hold the PROG button for 3 seconds until ALL DAYS appears. 2. - Page 15 Setting a 7-Day program – Individual Days (7-day programming mode only) Available Daily Events: MORN, DAY, EVE, NITE 1. Press and release the PROG button. 2. Press SYSTEM to select HEAT or COOL. 3. Press to select the day you want to program. Press NEXT. 4.
-
Page 16: Programming A 5-2 Day Schedule
Setting a 5-2 Day Weekday/Weekend Program (5-2 day programming mode only) Available Daily Events: MORN, DAY, EVE, NITE 1. Press and release the PROG button. 2. Press SYSTEM to select HEAT or COOL. 3. Press or to select WEEKDAYS or WEEKEND. Press NEXT. 4. -
Page 17: Operating Your Thermostat
4 Operating Your Thermostat Setting the SYSTEM Control Mode The System Control has 5 modes of operation – OFF, HEAT, EMR HEAT, AUTO and COOL. The mode can be selected by pressing the SYSTEM button to scroll through the different system modes. NOTE: Depending on how your thermostat was configured, some system modes may not be available. -
Page 18: Setting The Fan Control Mode
Setting the FAN Control Mode The Fan Control has 3 modes of operation – AUTO, ON, CIRC. The mode can be selected by pressing the FAN button to scroll through the different fan modes. NOTE: Depending on how your thermostat was configured, some fan modes may not be available. AUTO The system fan will run only when your heating or cooling system is running. -
Page 19: Temperature Adjustment
Temperature Adjustment Temporary Adjustment (OVERRIDE) – Press to adjust the current set temperature. The set temperature will change back to your programmed temperature a few hours later or at the start of the next scheduled program event. OVERRIDE will appear in the display during the entire override period. Extended Adjustment (HOLD) –... -
Page 20: System Status And Maintenance Indicators
System Status and Maintenance Indicators Status indicators are messages or symbols that appear in the display to let you know what function your system is currently performing. They are also used to inform you of various service and maintenance functions. HEAT ON The heating system is running. - Page 21 System Status and Maintenance Indicators (continued) HIGH LIM Setpoint temperature has reached its upper limit maximum. LOW LIM Setpoint temperature has reached its lower limit maximum. HI TEMP Room temperature has risen above the display range. Cooling will still operate to help lower temperature.
- Page 22 System Status and Maintenance Indicators (continued) LOCKED Thermostat has been fully or partially locked. See Locking and Unlocking thermostat, section 5. SERVICE A user selectable service reminder for changing the filter has be triggered. To set or reset these reminders, see User Options, section 2. NO POWER AC power to thermostat has been lost.
-
Page 23: Additional Operation Features
5 Additional Operating Features Auto Changeover Mode When Auto Changeover mode is enabled and selected, the system automatically switches between heating and cooling when the room temperature meets the current heating or cooling set points. To operate properly, the thermostat maintains a forced separation between the heating and cooling setpoints to prevent these systems from working against each other. -
Page 24: Circulating Fan Mode
Circulating Fan Mode Circulating Fan Mode is selected by touching the FAN button until CIRC appears in the display. When in CIRC mode the fan operates as required by the heating and cooling system (just like AUTO mode). When heating or cooling is not active, fan will run as needed to ensure a 35% minimum run time. -
Page 25: Locking And Unlocking The Thermostat
Locking and Unlocking the Thermostat Your 3-digit Lock Code is set in the User Settings portion of this manual (section 2). Once the code is set, the thermostat can be locked or unlocked at any time by entering that code. To lock or unlock the thermostat, press and hold the PROG and HOLD buttons together for 5 seconds. -
Page 26: Wi-Fi Connection
Wi-Fi Connection This thermostat is capable of connecting to a Wi-Fi network to enable remote monitoring and control from a mobile device or PC. ® To connect to Wi-Fi, you’ll need the BlueLink Smart Connect application on an iOS or Android device. -
Page 27: Thermostat Maintenance
6 Thermostat Maintenance Changing the Batteries Depending on your installation, this thermostat may be equipped with two (2) “AA” type alkaline batteries. If batteries are installed and they become low, the battery symbol appears in the display. When the batteries become critically low, the battery symbol will flash, and CHANGE / BATTERY will alternate in the display. -
Page 28: Limited Warranty
When installed by a professional contractor, this product is backed by a 5 year limited warranty. Limitations apply. For limitations, terms and conditions, you may obtain a full copy of this warranty. Visit us online: www.braeburnonline.com/warranty, phone us: 866.268.5599 or write us: Braeburn Systems LLC, 2215 Cornell Avenue, Montgomery, IL 60538. YEAR...
