Installer Manual
Universal Smart Wi-Fi Thermostat
8205 Up to 3 Heat / 2 Cool Heat Pump
1 Specifications 2 Installation 3 Wiring 4 Quick Reference
5 Installer Settings 6 Wi-Fi Setup 7 System Testing
Warning
For installation by experienced service technicians only.
Caution
Possible electric shock or damage to equipment can occur.
Disconnect power before beginning installation.
This thermostat requires 2 properly installed "AA" Alkaline batteries for proper
operation. When connecting optional 24 Volt AC power the batteries may be installed
as a backup. For some system types, a 24 VAC common (C wire) may be required.
Thermostat installation and all components of the system shall conform to Class II
Circuits per NEC code.
F
or use only as described in this manual. Any other use will void warranty.
1 Specifications
This thermostat is compatible with:
• Single stage heat / cool conventional and heat pump systems
• Conventional systems up to 2 stages of heating and 2 stages of cooling
• Heat pump systems up to 3 stages of heating and 2 stages of cooling
Electrical and control specifications:
• Electrical Rating: 24 Volt AC
• 1 amp maximum load per terminal
• AC Power: 18 – 30 Volts AC
• DC Power: 3.0 Volt DC (2 "AA" Alkaline Batteries Included)
• Control Range: 45° – 90° F (7° – 32° C)
• Temperature Accuracy: +/- 1° F (+/- .5° C)
Terminations
Rh, Rc, G, W1/E/W3, W2/AUX, Y1, Y2, O/B
Up to 2 Heat / 2 Cool Conventional
Model and serial number are located on back of thermostat.
®
®
8205-100-02
Advertisement
Table of Contents
Related Manuals for Braeburn 8205
Summary of Contents for Braeburn 8205
- Page 1 Installer Manual ® Universal Smart Wi-Fi Thermostat 8205 Up to 3 Heat / 2 Cool Heat Pump Up to 2 Heat / 2 Cool Conventional Model and serial number are located on back of thermostat. 1 Specifications 2 Installation 3 Wiring 4 Quick Reference...
-
Page 2: Installation
Avoid installation in locations where the thermostat can be affected by drafts, dead air spots, hot or cold air ducts, sunlight, appliances, concealed pipes, chimneys and outside walls. Install your New Braeburn Thermostat in 4 Easy Steps 1 Install the Sub-Base... - Page 3 Connect Your Wires Connect your wires as required for your system type. Refer to Section 3 - Wiring, on pages 4-5 for more information. 24VAC Power Terminal (C) Provide Power to Thermostat • Battery Power - Insert the 2 supplied “AA” type alkaline batteries into the battery compartment located in the rear housing of the thermostat.
- Page 4 3 Wiring Conventional Systems Typical Wiring Configurations Heat Only Cool Only 1 Heat/1 Cool 2 Heat/2 Cool Wiring Terminal Description System Type: System Type: System Type: System Type: Terminal CONV 11 CONV 11 CONV 11 CONV 22 24 VAC Heating Transformer 24 VAC Cooling Transformer Fan Relay (W1) Conventional Heat Relay...
- Page 5 3 Wiring Heat Pump Systems Typical Wiring Configurations 1 Heat/1 Cool 2 Heat/2 Cool 3 Heat/2 Cool 2 Heat/2 Cool Wiring (w/Aux Heat) (w/Aux Heat) Terminal Description Terminal System Type: System Type: System Type: System Type: HP 11 HP 22 HP 32 HP 32 24 VAC Heating Transformer...
-
Page 6: Quick Reference
4 Quick Reference Thermostat Display Room Temperature ...... Displays the current room temperature Set Temperature ......Displays the current set point temperature Fan Indicator ........ Indicates when the system fan is running Fan Mode Indicator ......Indicates the current fan mode Wi-Fi Indicator ...... - Page 7 4 Quick Reference Thermostat SYSTEM Button ..... Selects the system you want to control PROG Button......Enters programming mode or hold for 3 seconds to enter SpeedSet mode ® BACK Button* ......Secondary function of the PROG button - Moves to previous setting HOLD Button ......
-
Page 8: Installer Settings
5 Installer Settings The Installer Settings must be properly configured in order for this thermostat to operate correctly. The Installer Settings are menu driven. The portion of these settings that do not apply to your setup will be skipped. To Enter Installer Settings Menu 1 Press and hold the MENU button for 5 seconds. - Page 9 No. Installer Setting Displayed Default Available Description of Setting Settings Available Settings Auto-Changeover disabled AUTO CNG Auto Changeover Auto-Changeover enabled When auto-changeover mode is enabled and selected, the system can automatically switch between heating and cooling modes. There is a 5 minute delay when switching modes if auto changeover is selected. Auto changeover may affect your setpoint limit options in settings 21-24.
- Page 10 No. Installer Setting Displayed Default Available Description of Setting Settings Available Settings RECOVER Adaptive Recovery Adaptive Recovery Mode is disabled Mode (ARM Adaptive Recovery Mode is enabled [Not available if non-programmable was selected in setting 1] During ARM, room temperature is recovered by turning on the heating or cooling up to 3-hours before the end of the set back period.
- Page 11 6 Wi-Fi Setup Set-Up for Connection ® Before beginning Wi-Fi setup you will need to: • Wire and install the thermostat • Know the Wi-Fi network name and password • Have a valid e-mail address for the account • Locate your thermostat serial number •...
- Page 12 Wi-Fi Menu The Wi-Fi Menu allows you to connect your thermostat to a Wi-Fi network, review the saved Wi-Fi network information, and to clear Wi-Fi connection when necessary. To Enter the Wi-Fi Menu 1 Press and release the MENU button 2 Use the buttons to select WIFI SET 3 Press NEXT (HOLD) to confirm this choice and enter the...
- Page 13 Troubleshooting Wi-Fi Connection Issues The following error messages may be encountered when connecting to Wi-Fi. NO POWER Indicates the thermostat does not have sufficient power to operate Wi-Fi. Make sure the thermostat is snapped securely on the sub-base. Check the power to the heating and cooling equipment, and try again.
-
Page 14: System Testing
7 System Testing Warning Read Before Testing • Do not short (or jumper) across terminals on the gas valve or at the heating or cooling system control board to test the thermostat installation. This could damage the thermostat and void the warranty. •... - Page 15 Regulatory Statements This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 16: Limited Warranty
Store this manual for futur e reference. Stor e reference. www.braeburnonline.com ® Braeburn Systems LLC 2215 Cornell Avenue • Montgomery, IL 60538 Technical Assistance: www.braeburnonline.com 844-BLU-LINK (844-258-5465) (U.S.) 630-844-1968 (Outside the U.S.) 8205-100-02 ©2024 Braeburn Systems LLC • All Rights Reserved.
