Chapter 2 Overview
This chapter describes the unpacking and set up of the printer. Before proceeding to this chapter,
please make sure read the Chapter 1. Important Safety Instruction is acknowledged carefully.
Open the box
Open the box and
1
remove the accessories
and the cushion.
Remove the cardboard.
5
Remove the drip tray packaging
8
tapes.
Attention
● Retain the box and packing material. If the need arises,it will be used to transport the unit.
● This device without packing material or box is wighted around 23Kg (50lb). Handle the printer carefully to
prevent personal injury and damage of the printer.
P 5
Note: Cable tie illustrated in step 4 in this section is used to fix the extruder during transportation.
It should be removed before powering on the printer, or the printer may not funtion normally.
Take out the printer
2
by holding the side
handles.
Remove the print bed shipping tapes and
6
foam cushioning pieces.
Use the USB cable to connect the
9
printer to PC. Connect the power
cord to the printer then turn on the
power switch.
Remove plastic
3
4
bag and tapes.
7
A A A
B B B
Tapex2
Packing support x2
Open the top cover, then remove
packaging supports and tapes from
inside.
Remove the bottom screw and the
plastic piece under print bed.
Cable tie x1
