da Vinci 1.0/1.0A User Manual
Cartridge Slot
Remove the
packaging supports
USB Port
Power switch
Power Connector
Display Panel: information on printer status.
Control Panel: use to operate functions in the printer.
Extruder Module: to be used for printing 3D objects.
Z-Axis Rod: to be used to provide print-enabled lifting heated bed module.
Front Door: to be used for operating or maintenance.
Print bed: provides a flat surface to lay the 3D model.
Cartridge Slot: space for placing the filament cartridge.
USB Port: used for connecting the USB cable.
Power switch: this switch turns on/off the power of the printer.
Power Connector: to be used to connect the power cord.
Attention
Once the 3D printer is turned off, wait at least 3 seconds before turning it on again.
．User QuICK Guide
．Glue Stick
．Software CD
P 6
．Cartridge Locker
．Filament Cartridge
．Decorative Plate x2
Control Panel
Display Panel
Extruder Module
Z-Axis Rod
Control Panel
Front Door
Remove the
heated bed fixing
screws and
printing module
fixers
． Copper Brush
． Scraper
． Cleaning Wirex 5
．USB Cable
．Power Cord
