Press „Connect".
†
Press OK on the time switch.
†
▻ The display shows BLUETOOTH ACTIVE.
Press „Close" in the app within 30 s.
†
Now, for example, projects can be created and uploaded.

Resetting the time switch

Press the 4 buttons simultaneously.
†
▻ You can choose between RETAIN PROGRAM
and DELETE PROGRAM.

7. Technical Data

Operating voltage
Frequency
Standby
Max switching capacity
Switching capacity
Min. switching capacity
Switch output
Switch output 1700130 + 1704130
Switch output
Protection rating
Protection class
Operating temperature*
Power reserve
Switching accuracy
Time accuracy (typical)
Rated impulse voltage
Pollution degree
Software class
Contact
Max. switching cycles with 16 A resistive
load
Incandescent lamp load
Halogen lamp load
Fluorescent lamps (LLB low-loss bal-
lasts):
uncorrected
series-corrected
parallel-corrected
Compact fluorescent lamps (EB)
LED-lamps (< 2 W)
LED-lamps (> 2 W)
Bluetooth OBELISK top3
– Protection rating
– Temperature
– Range
1704130/1700130/1740130:
*Rigid cables (s): 16 A/55 °C
Flexible cables (f): 13 A/45 °C

Cleaning and service

Only use a dry, soft cloth to clean the device surface.
†
Do not use any cleaning agents or solvents.
†
