307038 Digital twilight switch LUNA 111 top2 1110100/ 1110200 LUNA 112 top2 1120100/ 1120200 1. Basic safety information 2. Proper use Disposal 3. Installation and connection 5 Mounting the time switch Connecting the cable Disconnecting the cable Connection/installation of light sensor 4. - Page 2 Display & buttons Operating instructions Overview of navigation menu 12 Initial operation 5. Settings and functions Set lux values Set delay Allocate sensors Activating PIN code Setting manual or permanent switching Set external input Hour counter Using the OBELISK top2 memory card Resetting the twilight switch 20...
- Page 3 6. Technical data 7. Contact...
-
Page 4: Basic Safety Information
1. Basic safety information WARNING Danger of death through electric shock or fire! ¾ ¾ Installation should only be carried out by a qualiied electrician! • The device is designed for installation on DIN top hat rails (in accordance with EN 60715) OBELISK top2 memory card: Avoid mechanical overload and contamination during storage/transportation 2. -
Page 5: Installation And Connection
3. Installation and connection Mounting the time switch WARNING Danger of death through electric shock or fire! ¾ ¾ Installation should only be carried out by a qualiied electrician! click... - Page 6 45° cable Load line connection Plug-in screwless termi- nal NC contact Test tap OBELISK top2 memory card (9070404) † ¾ Mount on DIN top hat rails (as deined in EN 60715) † ¾ Switched voltage-free † ¾ Ensure device cannot be switched on †...
-
Page 7: Connecting The Cable
Connecting the cable Wiring diagrams LUNA 111 top2 / LUNA 112 top2 4 5 6 Ext1 – + Ext1Ext2 Data – + Data 1 2 3 1 2 3 † ¾ Strip cable to 8 mm (max. 9) † ¾... -
Page 8: Connection/Installation Of Light Sensor
Connection/installation of light sensor Take length of connection cable into account: max. 100 m (2 x 1.5 mm ), max. 50 m (2 x 0.75 mm Avoid running sensor wiring parallel to mains power cables † ¾ Ensure correct polarity. Connect power source Mounting light sensor 907 0 415 †... - Page 9 8-9 mm max. 10 mm Ø 5-10 mm <9 mm Ø 20 mm IP 40 IP 66 ca. 63 mm...
-
Page 10: Device Description
4. Device description Display & buttons Sunrise/sunset Text line messwert display Lux value display Channel status C1, C2 ON = On OFF = Off Display of the active buttons with the relevant function ¾ ¾ MENU MENU – Activate display –... -
Page 11: Operating Instructions
Operating instructions 1. Read text line text/symbol represents query 2. Make a decision Modify/ Confirmation Change Press Press... -
Page 12: Overview Of Navigation Menu
Overview of navigation menu MENU MANUAL OPTIONS LIGHT 19 10 15 C1 OFF C2 OFF 9:40 CHANNEL C1 CHANNEL C1 SENSORS LUX VALUES PERM ON OPERATING HOUR DELAY TIME PERM OFF EXT INPUT OVERRI ON ILLUMINATION TIMER LANGUAGE FACTORY SETTINGS INFO Initial operation DEUTSCH... -
Page 13: Settings And Functions
L If all settings are performed, the screen alternately shows the automatic display and READING L If a sensor is connected, the measured lux value appears on screen (only during mains operation). 5. Settings and functions Set lux values MENU LIGHT CHANNEL C1 LUX VALUES... -
Page 14: Set Delay
Typical brightness values Daylight (bright) 80.000 lx Ofice accommodation 500 lx Hallways and stairs 100–150 lx Street lighting 15 lx Full moon ca. 0,3 lx Set delay MENU CHANNEL LIGHT LUX VALUES DELAY TIME ON DELAY MINUTE SECONDS OFF DELAY MINUTE SECONDS L An on/off delay of 1 minute is preset to avoid faulty ope-... -
Page 15: Allocate Sensors
The sensor that sends the lowest lux value is active Activating PIN code The PIN code is set in OPTIONS via the menu. L If you have forgotten your PIN, call the Theben Hotline. L Have the serial number ready. -
Page 16: Setting Manual Or Permanent Switching
MENU OPTIONS SENSORS OPERATING HOUR EXT- INPUT LLUMINATION LANGUAGE NO PIN FACTORY WITH PIN CURRENT PIN SETTING INFO NEW PIN 00 00 Setting manual or permanent switching Manual or permanent switching can be set via the menu in MANUAL or (in the automatic screen) by button combination (see picture). -
Page 17: Set External Input
Channel Channel Activating manual control † ¾ Briely press both buttons simultaneously Activating permanent switching † ¾ Press both buttons simultaneously for 2 seconds Cancelling manual/permanent switching † ¾ Press both buttons simultaneously Set external input For the channel, an EXTERNAL INPUT (see igure) can be set with different functions. -
Page 18: Hour Counter
MENU OPTIONS SENSORS Use switch without glow lamp (e.g. in stairwells) OPERATING HOUR EXT INPUT CHANNEL C1 BUTTON STAIRCASE LIGHT SWITCH ILLUMINATION OVERRIDE NOT ACTIVE TIMER RESETABLE MINUTES EARLY CUT Press MENU, with u select EXT INPUT and follow the indi- †... -
Page 19: Using The Obelisk Top2 Memory Card
¾ Read in/out saved switching times and device setups in the time switch or start Obelisk program † ¾ Remove memory card after copying etc. Avoid mechanical overload and contamination during storage/transport L PC software OBELISK top2 available at www.theben.de... -
Page 20: Resetting The Twilight Switch
Copying OBELISK → LUNA This copies the switching program and optionally all time switch settings (e.g. external input, time format etc.) from the memory card in the twilight switch. Copying LUNA →OBELISK This copies all switch programmes and settings from the twilight switch to the memory card. - Page 21 6. Technical data Operating voltage: 230–240 V~(LUNA 111 top2 RC) / 100–240 V~ (LUNA 112 top2 RC), +10 %/-15 % Frequency: 50–60 Hz Brightness range: 1–99,000 lx On/off switch delay: 0–59 min Power consumption Luna 121 / Luna 122: 1,8 W / 2,2 W...
- Page 22 IP 20 Mounted light sensor IP 55 Installation light sensor IP 66 (frontside) IP 40 (backside) 7. Contact Theben AG Hohenbergstr. 32 72401 Haigerloch GERMANY Tel. +49 7474 692-0 Fax +49 7474 692-150 Hotline Tel. +49 7474 692-369 hotline@theben.de Addresses, telephone numbers etc.
