Set the Time Information
Navigate: Main Menu → Info → Time Info
Parameter
Current Time
Ttl Life Hrs
Last Run Hrs
LED Hours
Timer PIN
Clr Last Run
LED Time PIN
Clear LED Time
View Fixture Errors
Navigate: Main Menu → Info → Error History
Displays any current fixture errors. See
errors.
View DMX Values for Channels
Navigate: Main Menu → Info → DMX Value
View the DMX value of one of the fixture's channels. Scroll to the channel that you want to
view (Pan Coarse, Pan Fine, etc.) and press the Enter button. The DMX value of the channel
you chose is shown in the main window of the UI.
View Fan Speeds
Navigate: Main Menu → Info → Fan Speed
Displays the speeds of the fixture's fans (in RPM).
Configure the Fixture
Value Description
XXXX (Hours) Running time of the fixture from the last time that the
fixture was powered on, shown in hours (h). The
counter resets after the fixture is turned off.
XXXX (Hours) Total running time of the fixture, shown in hours (h).
XXXX (Hours) Running time of the fixture from the last time that the
run time value was reset, shown in hours (h).
XXXX (Hours) Total running time of the fixture LEDs, shown in
hours (h).
Timer PIN XXX You must enter the Timer PIN in order to access the
Clr Last Run menu item. The default Timer PIN is 038.
• ON This password-protected menu item resets the Last
Run Hrs value. You must enter the Timer PIN to access
• OFF
this menu item.
Select ON to clear the value for the Last Run Hrs
parameter for the fixture.
LED Time PIN XXX You must enter the LED Time PIN in order to access
the Clear LED Time menu item. The default LED Time
PIN is 038.
• ON This password-protected menu item resets the LED
Hours value. You must enter the LED Time PIN to
• OFF
access this menu item.
Select ON to clear the value for the LED Hours
parameter.
Error Codes on page 24 for information about the
