ETC High End Systems Zeo User Manual page 11

Specifications
For complete technical specifications, see the technical datasheet:
etcconnect.com/Zeo/Documentation.
Environment
• Ambient operating temperature range: -10°C to 40°C (14°F to 104°F).
• Relative humidity: 0%–90%, non-condensing.
• Storage temperature: -20°C to 60°C (-4°F to 140°F).
• Indoor use only.
• Dry locations only, IP20 rated.
Power
WARNING:
to avoid damage to the fixture's internal power supply and other electrical
components. Using a dimmable power source can damage the fixture and
will void the warranty.
Electrical
• 100–240 VAC at 50/60 Hz
• Listed maximum wattage: 1670 W
Input and Power Factor
The values listed below were measured with the fixture in Standard mode with LEDs at full and
all motors functioning.
VAC Amps
100 16.8
120 13.4
200 7.6
208 7.3
220 6.9
230 6.6
240 6.3
Fixtures per Circuit
One fixture is allowed per circuit via an ETC R20 or similar breaker module. Consult the
upstream breaker trip curves when using other equipment.
Specifications
Connect the fixture to a non-dimmable power source in order
Hz Watts VA
50 1670 1676
60 1597 1596
50 1497 1512
60 1487 1501
50 1485 1504
50 1475 1495
60 1466 1492
PF
0.99
0.99
0.98
0.98
0.98
0.98
0.98
7
