Specifications and
B
Environment
The following specifications are standard except where noted.
System Processor
P24C-75Mhz (Intel 486 DX4-75)
Random Access Memory (RAM)
Standard Main Memory —
Expansion Optional
8-MB, 16-MB increments. Maximum 36MB or 40MB total.
Video RAM
Cache RAM
Read-only Memory (ROM)
256-KB x 8 bit, Flash ROM
Calendar Clock
Year/month/day/hour/minute/second maintained by internal back-up battery
Input/Output (I/O) Facilities
Integrated industry-standard interfaces
Parallel
Serial
VGA — 1 port, 15-pin high-density D-sub
E32bit Local Bus
EHardware Windows Acceleration
4-MB high-speed interleaved access (DSTN model)
8-MB high-speed interleaved access (Active-matrix
model)
Two slots for DIMM sockets. Expandable in 4-MB,
1 MB
L2: 128-KB (DX4-100 only)
1 port, 25-pin D-sub
1 port, 9-pin D-sub
Specifications and Environment B-1
