5.13. USB (USB 2.0)

USB (Universal Serial Bus) allows a PC to connect with up to 127 devices.
In addition, the USB provides a plug & play feature, allowing the connection and disconnection of a
device while ShieldPRO is powered on.
Available USB devices include pointing devices, printers, digital cameras, mobile phones and other
computer ancillaries.
Some USB devices require driver installations and/or switch settings before or after they are connected
to ShieldPRO.
Refer to the User's Guides of USB devices to be connected to ShieldPRO before using them.
After disconnecting a USB device from ShieldPRO, wait for three seconds or longer before the device is
connected again.
If the connector of a USB device is connected to ShieldPRO quickly or at an angle, ShieldPRO may not
be able to read signals properly to recognise it as an unknown device. If so, remove the connector from
the USB connector and reconnect it again.
Do not connect or remove a USB device to/from ShieldPRO in suspend (standby) state, transition to
suspend (standby) state, recovery from suspend (standby) state, hibernate state, transition to hibernate
state, or recovery from hibernate state.
If ShieldPRO connects with one or more USB devices, it may not be able to enter into suspend (standby)
state. Before ShieldPRO can be entered into suspend (standby) state, the USB devices must be
removed.
Some Operating Systems may limit the features of USB devices.
[Specification]
Standard:
Voltage:
Current:
5.13.1.

Connecting USB devices to ShieldPRO

ShieldPRO has three USB ports on the left side intended to connect with USB2.0 devices.
To connect a USB device to ShieldPRO, insert the plug of the USB cable to a USB connector on
ShieldPRO.
Note the orientation of the plug to be inserted to a USB connector.
5.13.2.

Removing USB devices from ShieldPRO

Connecting some USB devices may cause the icon for removing hardware to appear on the system
tray at the lower right corner of the screen.
USB2.0
5 VDC
0.5 A/port
NEC ShieldPRO FC-N21S Ruggedised Notebook Computer
User's Guide 0318-00002 Ver. 2.0 Dec 2008 – Page 59
