9.Operation

When 24VDC is supplied to the bar through the M8 connector, the status LED will illuminate green to
indicate it is running correctly with a good ion output.

9.1.Output setup

The 945IPS has variable outputs that can be monitored and adjusted using a BarMaster or
SmartControl, to ensure optimum performance. The output values should be set dependent on both
the target object and its distance from the bar.

9.1.1.Output voltage

The default voltage setting is 12.5kV. This combines both good performance and good emitter pin life.
For faster applications, the voltage can be increased.

9.1.2.Output frequency

The default frequency setting is 5Hz, which is effective for longer ranges of 450 to 600mm. For shorter
ranges of 150 to 450mm, the frequency can be increased for additional performance.

9.1.3.Output balance

The default balance setting is 58% (58:42 Pos:Neg). On applications where the target is charged with
a negative bias, the balance can be increased. Alternatively, targets with a positive bias should have
the balance reduced.

9.2.Standby input

The 945IPS can be put into standby mode. This is done by performing the following steps:
1. Adjust Pin 4 setting from Fault (output) to Standby (input) with a BarMaster.
2. When Pin 4 (Black) is connected to 0V, the bar will go into standby. See section 7.2 for details
on the input port.
Notice –
Ionising equipment will not operate at its optimum if the output
parameters are incorrectly set.
Ensure that after any adjustment is made, clean the bar as described in the
maintenance section.
