10.Technical & construction data
Dimensions (LxWxH)
Weight
Maximum ambient temperature 60
Mounting
Mounting height
Optimum operating range
Enclosure
Emitters
Electrical connections
Input current
Input voltage
Output voltage
Output frequency
Output balance
Alarm input/output
Alarm output drives
Local indication
Protection class
300 to 3900mm x 30mm x 67mm
Approx. 0.9kg/metre
o C
'T' slot with M4 x 35mm studs
To comply with UL 62368-1, the 945IPS must be mounted at a height
≤2m
150 to 600mm
FR ABS
Titanium pins
4-pin M8 & earth terminal
Maximum 625mA
24VDC (22 to 26VDC)
BarMaster or SmartControl adjustable between 2 to 15kV Pos/Neg
(Default 12.5kV)
BarMaster or SmartControl adjustable between 1 to 20Hz
(Default 5Hz)
BarMaster or SmartControl adjustable between 80:20 to 20:80
Pos:Neg (Default 58:42 Pos:Neg)
Dual outputs for Alert/Fault monitoring (0V/24V)
1x Alert output (eg. clean pin alert)
1x Fault output/standby input (adjustable via BarMaster)
Compatible with IEC 61131-2 type 1,2,3 plc inputs
Green/yellow/red LED
IP66 construction
