Bradley Express SS Series Installation Manual

Lavatory system
Hide thumbs Also See for Express SS Series:
Table of Contents

Advertisement

Quick Links

Download this manual
SS-1N/IR Express® Lavatory
System shown with optional
acrylic trap cover
SS-1N/TT Express® Lavatory System
shown with optional stainless steel trap
cover and soap dispenser model 6315
215-1600 Rev. C; ECN 07-814
© 2007 Bradley Corporation
Page 1 of 27
12/11/07
Installation
SS-1N (bowl only)
SS-1N/IR
SS-1N/BIR3
SS-1N/TT
Express® Lavatory System SS-Series
Patent Pending
For Reference Only

Table of Contents

Supplies Required for Installation . . . . . . . . . . . . . . . . . . . .2
Assembly of Components . . . . . . . . . . . . . . . . . . . . . . . .3-4
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-9
Mounting Bowl to Wall . . . . . . . . . . . . . . . . . . . . . . . .10-11
Electronic Valve Installation
Adaptive Infrared Activation . . . . . . . . . . . . . . . . . . . . 12
Battery Infrared Activation . . . . . . . . . . . . . . . . . . .13-14
TouchTime® Activation . . . . . . . . . . . . . . . . . . . . . . . . .15
Water Heater Installation . . . . . . . . . . . . . . . . . . . . . . . . . .16
Drain Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . .18
Adaptive Infrared Repair Parts . . . . . . . . . . . . . . . . . . . . .19
Battery Infrared Repair Parts . . . . . . . . . . . . . . . . . . . . . . .20
TouchTime® Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . .21
VAC Solenoid Valve Troubleshooting . . . . . . . . . . . . . . . .22
VAC Solenoid Valve Repair Parts . . . . . . . . . . . . . . . . . . .23
BIR3 Solenoid Valve Troubleshooting . . . . . . . . . . . . . . .24
BIR3 Solenoid Valve Repair Parts . . . . . . . . . . . . . . . . . . .25
Vernatherm Valve Maintenances . . . . . . . . . . . . . . . . . . . .26
Vernatherm Valve Repair Parts . . . . . . . . . . . . . . . . . . . . .27
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: (262) 251-5817
http:\\www.bradleycorp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Express SS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bradley Express SS Series

Summary of Contents for Bradley Express SS Series

  • Page 1: Table Of Contents

    Vernatherm Valve Repair Parts .....27 215-1600 Rev. C; ECN 07-814 P.O. Box 309, Menomonee Falls, WI 53052-0309 Phone: 1-800-BRADLEY Fax: (262) 251-5817 © 2007 Bradley Corporation http:\\www.bradleycorp.com...

  • Page 2: Supplies Required For Installation

    Hardware supplied by installer must be appropriate for wall construction. Wall anchors used must have a minimum pull-out rating of 1,000 lbs. Product warranties may be found under "Product Information" on our web site at www.bradleycorp.com. 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 3: Assembly Of Components

    (Model 6315) (Model 6322) (individual component part 27 oz. 1000-shot Refills numbers listed on page 10) Case of 4 (P19-232B) 54 oz. 2000-shot Refills Case of 4 (P19-232A) AC plug-in Adapter (P19-231F) Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...
  • Page 4 WATER HEATER for I.R. and TOUCHTIME® OPTION ONLY EX95TMLB (S45-2201, 240/208 volts) EX100TMLB (S45-2202, 277 volts) For Reference Only TEMPERED LINE for TEMPERED LINE for BIR3 OPTION I.R. and TOUCHTIME® OPTION (S08-431TL) (S08-411TL) 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...
  • Page 5 (102mm) (102mm) (152mm) (178mm) 21-1/2" 19-3/4" (546mm) (502mm) 8-7/8" 13" 11-1/4" 8" (225mm) (330mm) (286mm) (203mm) REF. REF. *Subtract 4" from vertical dimensions for compliance with ADA guidelines for children's use. Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...
  • Page 6 (330mm) GRADES THROUGH PRE-K 8 OR 9 THROUGH 5 OR 6 36-1/2" (927mm) 34-1/2" (876mm) 32" 10-3/4" 30" (813mm) (273mm) (762mm) 10-3/4" (273mm) 28" 26" (711mm) (660mm) 15" 13" (381mm) (330mm) 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 7: Rough-Ins

    NOTE: If an acrylic trap cover is supplied, refer to the rough-in requirements shown in the Front View on page 5. If a stainless steel trap cover is supplied, refer to the rough-in requirements in the Front View shown above. For Reference Only Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...
  • Page 8 34" NONE STANDARD HEIGHT 32" SUBTRACT 2" TAS - GRADES 6 THROUGH 8 OR 9 31" SUBTRACT 3" JUVENILE HEIGHT 30" SUBTRACT 4" TAS - GRADES PRE-K THROUGH 5 OR 6 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 9: Dimensions

    1/4"-20 WALL ANCHORS 30-1/4" FLOOR MIN. PULL-OUT FORCE (768mm) 1,000 LBS PER ANCHOR (6) PLACES FINISHED FLOOR CLEARANCE SLOT FOR OPTIONAL VALVE BRACKET 7-3/4" (197mm) DIMENSIONS ARE SYMMETRICAL ABOUT CENTERLINE Figure 1c Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 10: Mounting Bowl To Wall

    2. Use 1/4" screws (supplied by installer) and washers (supplied by Bradley) to attach the backplate weldment to the wall (refer to Figure 1c. 3. Screw the two locking devices (supplied by Bradley) into the bracket arm at the center 1/4-20 tap location shown in Figure 2b on page 11 (one locking device per arm).
  • Page 11 Figure 2b (incl. in Prepack 269-1712) BOWL SS-1N LEVELING SCREW LEVELING LOCKING SCREW Figure 2c DEVICE 1/4"-20 BACKPLATE SET SCREWS WELDMENT LEVELING SCREW 8-1/2" (216mm) LOCKING DEVICE BRACKET LEVELING SCREW Figure 2d Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 12: Adaptive Infrared Activation

    MIXING VALVE OPTION SHOWN, FEMALE CONNECTOR TEMPERED LINE FROM POWER CORD OPTION IS SIMILAR FEMALE CONNECTOR FROM SPRAYHEAD SENSOR COLD FEMALE CONNECTORS TO MALE CONNECTORS COLD ON TRANSFORMER Figure 3a-1 Figure 3a-3 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 13: Battery Infrared Activation

    (see Figure 3b-2 on page 14). For Reference Only SENSOR EYES FROM BIR3 CIRCUIT BOARD SPRAYHEAD SUPPLY TUBE MOUNTING HOLES MIXING VALVE OPTION SHOWN, BIR3 VALVE ASM. TEMPERED LINE OPTION IS SIMILAR Figure 3b-1 Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...
  • Page 14 13). COMPRESSION NOTE: Proceed to Step 5, page 17 for drain installation. SENSOR PLUG BATTERY For Reference Only HOLDER PLUG COLD Figure 3b-3 BATTERY HOLDER 6-volt LITHIUM BATTERY Figure 3b-4 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 15: Touchtime® Activation

    COMPRESSION TRANSFORMER MOUNTING HOLES GREEN OUTPUT WIRE TO SOLENOID MIXING VALVE OPTION SHOWN, GRAY TEMPERED LINE OUTPUT WIRE OPTION IS SIMILAR TO SOLENOID COLD COLD SOLENOID Figure 3c-1 Figure 3c-3 COLD Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 16: Water Heater Installation

    4. Secure the water heater to the underside of the SS-1N bowl using the two #10 screws supplied. #10 SCREWS CHECK/STOP (S27-102) HOT WATER HEATER 240/208V (269-1767) 277V (269-1768) TEMPERED SUPPLY OUTLET INLET 1/2" FLEXIBLE HOSE (269-1735) Figure 4b 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 17: Drain Installation

    3. Assemble the P-trap by connecting the 1-1/2" tubular pipe to the tailpiece and to the 1-1/2" drain pipe stubbed out of the wall. For Reference Only STRAINER DRAIN HOLE SS-1N BOWL RUBBER WASHER TAILPIECE 1-1/2" P-TRAP Figure 5 Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 18: Cleaning And Maintenance

    #7448 Scotch-Brite pad or with an abrasive cleaner. • Repair kit: In the unlikely event your Terreon® surface becomes damaged, it can easily be repaired. Contact your Bradley representative to order a repair kit and be sure to specify color. Trap Cover cleaning IMPORTANT: Do not use abrasive cleansers to clean the panel.

  • Page 19: Adaptive Infrared Repair Parts

    SENSOR (269-1608) HOOK & LOOP FASTENER 1/4"-20 (P10-569) THREADED ROD (176-119) 1/4" LOCKWASHER (142-002BS) CLIP (269-1219) 1/4"-20 NUT (161-026) LEAD WIRE (S53-259A) PIGTAIL LEAD ASSY. 1/4" TUBING (S83-103) (R68-600011) TRANSFORMER S83-181 Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 20: Replacement Parts

    CLOSED BODY (S07-083) LENGTH OF “A” = 36" (251-019A) CIRCUIT BOARD LENGTH OF “A” = 60" (251-019B) WITH STANDOFF (S83-178) VALVE ASSEMBLY CLOSED BODY (S07-073) PAN-HEAD SCREW 6-19 x 3/4" (160-451) 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 21: Touchtime® Repair Parts

    1/4" LOCKWASHER ELBOW (142-002BS) (145-090) FLAT WASHER (142-002AZ) For Reference Only TOUCH TIME™ SWITCH (S83-139B) (110-115) O-RING 1/4" TUBING (125-001CK) (R68-600011) #10-24 SCREW (160-214) DIFFUSER (269-508) STREAMFORMER #8-32 SCREW (115-125) (160-289) Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 22: Vac Solenoid Valve Troubleshooting

    • reconnect to the adjacent valve and turn on the water supplies to the unit; • pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor (see page 19). 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 23: Vac Solenoid Valve Repair Parts

    269-577 ARMATURE 269-578 SPRING 269-1729 ARMATURE HOUSING 269-1730 CLAMP, ARMATURE HOUSING 269-579 COIL, SOLENOID VALVE 160-447 SCREW, #8 X 5/8 125-165 O-RING, #2-013 125-160 FLOW RESTRICTOR, .5 GPM For Reference Only Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 24: Troubleshooting Bir3 Components

    Make a note of the numbers printed on the circuit board, then contact your Bradley representative for assistance. CLOSED VALVE 12/11/07 Bradley Corporation • 215-1600 Rev. C; ECN 07-814...

  • Page 25: Bir3 Solenoid Valve Repair Parts

    192-017 ARMATURE 135-093 SPRING 269-1729 ARMATURE HOUSING 269-1730 CLAMP, ARMATURE HOUSING 269-1731 COIL, SOLENOID VALVE 160-447 SCREW, #8 X 5/8 125-165 O-RING, #2-013 125-160 FLOW RESTRICTOR, .5 GPM For Reference Only Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

  • Page 26: Vernatherm Valve Maintenances

    Problem: Limited water flow Cause: Dirt and debris have built up in the valve or strainer. 1. Remove and clean strainer. If strainer needs to be replaced, order Bradley part no. 173-028. 2. Check the piston for smooth movement. To check the valve's piston for free and smooth movement, follow the procedures outlined below: 1.

  • Page 27: Vernatherm™ Thermostatic Mixing Valve

    Vernatherm™ Thermostatic Mixing Valve S01-524 Repair Kit S65-259 Nut 3/8-24 Hex Jam Item Description Thermostat O-Ring O-Ring O-Ring O-Ring For Reference Only Stem Thermostat Piston Spring Seal Cup Valve Body Strainer (173-028) Bradley Corporation • 215-1600 Rev. C; ECN 07-814 12/11/07...

This manual is also suitable for:

Express ss-1nExpress ss-1n/irExpress ss-1n/bir3Express ss-1n/tt
