Bradley Express SS-3/BIR/STD Installation Instructions Manual

Lavatory system
Hide thumbs

Advertisement

Quick Links

Download this manual
IMPORTANT
Read this entire installation manual
to ensure proper installation, then
file these instructions with the
owner or maintenance department.
Flush all the water supply lines
before making connections.
Wall anchors used must have a
minimum pull-out rating of 1,000
lbs.
Product warranties may be found
under "Product Information" on our
web site at www.bradleycorp.com.
215-1461 Rev. A; EN 03-813
© 2004 Bradley Corporation
Page 1 of 17
5/11/04
Installation
Instructions
For Service Only
SS-3/BIR/STD
SS-3/BIR/JUV
Express® Lavatory
System SS-Series
(Standard* and Juvenile Height)
*Express® Lavatory Systems
are ADA compliant.

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . .2
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Installation Instructions . . . . . . . . . . . . . . . . 5-11
Cleaning and Maintenance . . . . . . . . . . . . . . . .12
Soap Dispenser Maintenance . . . . . . . . . . .13-14
Check Valve Troubleshooting . . . . . . . . . . . . . .14
Assembly of Components . . . . . . . . . . . . . .15-16
Vernatherm™ Valve Maintenance . . . . . . . . . .17
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY
http://www.bradleycorp.com
FAX 262-251-5817

Advertisement

loading
Need help?

Need help?

Do you have a question about the Express SS-3/BIR/STD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bradley Express SS-3/BIR/STD

Summary of Contents for Bradley Express SS-3/BIR/STD

  • Page 1: Table Of Contents

    Product warranties may be found under "Product Information" on our web site at www.bradleycorp.com. P.O. Box 309, Menomonee Falls, WI 53052-0309 215-1461 Rev. A; EN 03-813 TEL. 1-800-BRADLEY FAX 262-251-5817 © 2004 Bradley Corporation http://www.bradleycorp.com Page 1 of 17 5/11/04...

  • Page 2: Pre-Installation Information

    • 1/2" NPT tempered supply piping • 1-1/2" NPT drain piping • (18) “AA” alkaline batteries • (1) 1/4" wall anchor, bolt and washer to mount center battery box to wall 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...

  • Page 3: Dimensions

    SS-3/BIR/STD Express® Lavatory System Dimensions Standard Height Mounting 68-1/4" (1732) 8" (203) 6" (152) 52" (1321) 64" (1626) 80" (2032) 8-1/2" (216) 21" (533) 10" (254) Radius 8" 30" 30" (203) (762) (762) Radius Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
  • Page 4 (965) 34" Standard Height (864) 29" SS-3/BIR/STD (737) 9" 4" (229) 6" (102) (152) 11" (279) 34" 30" (864) (762) 25" Juvenile Height (635) SS-3/BIR/JUV 9" 4" 6" (229) (102) (152) 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...

  • Page 5: Installation Instructions

    23-1/2" (89) FROM WALL ANCHOR (597mm) 21-1/4" (540mm) (8) 3/8" WALL TEMPERED ANCHORS WITH 11-3/8" SUPPLY MINIMUM PULL- (289mm) 15-1/4" OUT RATING OF (387mm) 1,000 LBS. FINISHED FLOOR CENTERLINE Figure 1a Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
  • Page 6 FINISHED FLOOR CENTERLINE Figure 1a BATTERY BOX #10- 24 SCREW (160-416) 1-1/2" NPT DRAIN BRACKET STUB-OUT WASHER (142-002DB) (140-913) 1/2" NPT HOT AND COLD SUPPLIES OR TEMPERED SUPPLY STUB-OUTS Figure 2 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...
  • Page 7 BATTERY BOX MOUNTS TO THE WALL. THE LEFT AND RIGHT SIDE BATTERY BOXES MOUNT TO THE FRAME. ATTACH THE GREEN SUPPLY TUBE TO THE 1/4" CONNECTOR ON THE CENTER BATTERY BOX. Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
  • Page 8 Do not tighten screws at this time. 3/8" BOLT AND WASHER BACK VIEW 3/8" BOLT WASHER BOWL ASSEMBLY FRAME 1/4"-20 X 3/8" PAN HEAD SCREWS AND Figure 5 WASHERS 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...
  • Page 9 9. Tighten the screws installed to secure the bowl assembly to the frame. Do not overtighten. COVER SCREWS (4) FLEX HOSE WASHER Figure 6a FILTER Figure 6b Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
  • Page 10 CONNECT TO CONNECT TO 1/2" NPT COLD 1/2" NPT HOT WATER SUPPLY WATER SUPPLY STOP/STRAINER CHECK VALVE 1/2" ELBOW (S60-003) (169-639) 1/2" CROSS (269-1585) 1/2" NIPPLE (113-006DH) Figure 7b Figure 8 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...
  • Page 11 4. After testing is complete, reinstall panel to frame. Fasten panel with the ten Torx-head screws provided (see Figure 3 on page 7). NOTE: For Express® units with optional soap dispensers, see pages 13 and 14 for soap dispenser maintenance instructions. Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...

  • Page 12: Cleaning And Maintenance

    Brite pad or with an abrasive cleaner. • Repair kit: In the unlikely event your Terreon® surface becomes damaged, it can easily and inexpensively be repaired. Contact your Bradley representative to order a repair kit and be sure to specify color when ordering.

  • Page 13: Soap Dispenser Maintenance

    Figure 9a ACTIVATION LABEL 204-476 (qty. 3) (one above each activation zone) FILLER HOLE SOAP TANK 133-107 (GRAY) 133-131 (PUTTY) 133-131A (COAL) (qty. 2) SOAP DISPENSER VALVE Figure 9b S09-007 (qty. 2) Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...

  • Page 14: Check Valve Troubleshooting

    3. Remove the flexible hoses from the stop/check valves and clean the strainers, if necessary. 4. Inspect mixing valve for proper installation (see Vernatherm valve on page 17). • A red marking indicates the hot inlet. 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...

  • Page 15: Assembly Of Components

    Vernatherm™ Thermostatic Mixing Valve Assembly S67-571 VERNATHERM VALVE (S01-116B) Optional Stop/Strainer/Check Valve 90° ELBOW FLEX HOSE WITH 169-639 SWIVEL END FILTER 269-653 WASHER 269-1188 STOP/CHECK VALVE S27-102 BRASS PIPE NIPPLE STOP/STRAINER/CHECK VALVE 113-006DJ S60-003 Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
  • Page 16 SINGLE OPERATION Drain Assembly CONTROL BOX S67-219 SENSOR ASSY. SCREW COMPONENTS 160-120 110-115 1/4" ELBOW 145-090 AERATOR INFRARED HOUSING WINDOW 115-133 269-1241 O-RING 125-001CK DIFFUSER 269-508 STREAMFORMER SCREW 115-125 160-289 5/11/04 Bradley Corporation • 215-1461 Rev. A; EN 03-813...

  • Page 17: Vernatherm™ Valve Maintenance

    No Water Cold Valve shuts off or drips Correct Correct Cold Cold Cold Reversed Cold Cold/below 107° Hot/above 107° Reversed No Water Reversed No Water Cold Cold Reversed Reversed Cold Cold Cold Bradley Corporation • 215-1461 Rev. A; EN 03-813 5/11/04...
