IMPORTANT
Read this entire installation manual
to ensure proper installation, then
file these instructions with the
owner or maintenance department.
Flush all the water supply lines
before making connections.
Wall anchors used must have a
minimum pull-out rating of 1,000
lbs.
Product warranties may be found
under "Product Information" on our
web site at www.bradleycorp.com.
215-1456 Rev. A; EN 03-813
© 2004 Bradley Corporation
Page 1 of 17
5/11/04
Installation
Instructions
For Service Only
SS-3/TT/WH97
Express® Lavatory
System SS-Series
Express® Lavatory Systems
are ADA compliant.

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . .2
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation Instructions . . . . . . . . . . . . . . . . . 4-9
Cleaning and Maintenance . . . . . . . . . . . . . . . .10
Soap Dispenser Maintenance . . . . . . . . . . .11-12
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . .12
Assembly of Components . . . . . . . . . . . . . .13-14
Check Valve Troubleshooting . . . . . . . . . . . . . .15
Solenoid Troubleshooting . . . . . . . . . . . . . .15-16
Vernatherm™ Mixing Valve . . . . . . . . . . . . . . .17
