S MLD S
HOWING NOOPING
S MLD
HOWING
S S
NOOPING TATUS
W I
EB NTERFACE
To display IGMP Source-Specific Information, click Monitor, IGMP Snooping,
IGMP SSM Information.

Figure 118: IPv4 SSM Information

I
NFORMATION
Use the MLD Snooping pages to display MLD snooping statistics, port
members of each service group, and information on source-specific groups.
Use the IGMP Snooping Status page to display MLD querier status and
snooping statistics for each VLAN carrying multicast traffic, and the ports
connected to an upstream multicast router/switch.
P
ATH
Monitor, IPMC, MLD Snooping, Status
P
ARAMETERS
These parameters are displayed:
Statistics
VLAN ID – VLAN Identifier.
◆
Querier Version – MLD version used by the switch when serving as
◆
the MLD querier.
Host Version – MLD version used when used by this switch when
◆
serving as a host in MLD proxy mode.
Querier Status – Shows the Querier status as "ACTIVE" or "IDLE."
◆
When enabled and selected through the bidding process, the switch can
serve as the Querier, which is responsible for asking hosts if they want
to receive multicast traffic.
Queries Transmitted – The number of transmitted Querier messages.
◆
◆ Queries Received – The number of received Querier messages.
V1 Reports Received – The number of received MLD Version 1
◆
reports.
– 241 –
| Monitoring the Switch
C 5
HAPTER

Showing MLD Snooping Information
