| Configuring the Switch
C 4
HAPTER
Configuring Security
W I
EB NTERFACE
To configure an Access Control List for a port or a policy:
Click Configuration, Security, Network, ACL, Access Control List.
1.
Click the button to add a new ACL, or use the other ACL
2.
modification buttons to specify the editing action (i.e., edit, delete, or
moving the relative position of entry in the list).
When editing an entry on the ACE Configuration page, note that the
3.
items displayed depend on various selections, such as Frame Type and
IP Protocol Type. Specify the relevant criteria to be matched for this
rule, and set the actions to take when a rule is matched (such as Rate
Limiter, Port Copy, Logging, and Shutdown).
Click Save.
4.

Figure 31: Access Control List Configuration

– 98 –
