To display LACP status for local ports this switch, click Monitor, LACP, Port
Status.

Figure 108: LACP Port Status

Use the LACP Port Statistics page to display statistics on LACP control
D LACP
ISPLAYING
packets crossing on each port.
P S
ORT TATISTICS
P
ATH
Monitor, LACP, Port Statistics
P
ARAMETERS
These parameters are displayed:
◆
◆
◆
◆
W
EB
To display LACP statistics for local ports this switch, click Monitor, LACP,
Port Statistics.

Figure 109: LACP Port Statistics

I
NTERFACE
Port – Port Identifier.
LACP Transmitted – The number of LACP frames sent from each port.
LACP Received – The number of LACP frames received at each port.
Discarded – The number of unknown or illegal LACP frames that have
been discarded at each port.
I
NTERFACE
– 231 –
| Monitoring the Switch
C 5
HAPTER
Displaying Information on LACP
