Summary of Contents for Beckhoff CP32 Series
- Page 1 Manual | EN CP32xx Panel PC 2024-11-20 | Version: 2.0...
-
Page 3: Table Of Contents
4.3.2 Connecting cables and power supply ................ 26 Switching the Panel PC on and off.................... 28 5 Configuration............................ 30 Beckhoff Device Manager ....................... 30 UPS configuration ........................... 31 6 Decommissioning ........................... 34 Disconnecting the power supply and cables ................... 34 Disassembly and disposal....................... 35 7 Maintenance ............................ 38... - Page 4 Table of contents Version: 2.0 CP32xx...
-
Page 5: Notes On The Documentation
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 and similar applications and registrations in several other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The distribution and reproduction of this document as well as the use and communication of its contents without express authorization are prohibited. -
Page 6: For Your Safety
Exclusion of liability Beckhoff shall not be held liable in the event that this documentation is not complied with and the devices are therefore not used in line with the documented operating conditions. -
Page 7: Fundamental Safety Instructions
For your safety Fundamental safety instructions The following safety instructions must be observed when handling the device. Application conditions • Do not use the device under extreme environmental conditions. • Only use the device in hazardous areas if it is explicitly designed for this purpose. •... -
Page 8: Notes On Information Security
For your safety Notes on information security The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online, are equipped with security functions that support the secure operation of plants, systems, machines and networks. Despite the security functions, the creation, implementation and constant updating of a holistic security concept for the operation are necessary to protect the respective plant, system, machine and networks against cyber threats. -
Page 9: Product Overview
Product overview Product overview With the CP32xx series, you can use multitouch as a high-end panel PC directly in the field. The devices in the robust aluminum housing are designed for mounting arm installation. The connection cables are routed through the mounting arm. Thanks to its processors, you can use the panel PC for the following applications, among others: •... -
Page 10: Structure
Product overview Structure Figure 1 shows the structure of the device as an example for all CP32xx variants. Fig. 1: Structure Table 1: Legend structure Component Description Display and touch screen glass Operation of the panel PC Locking screw Anti-twist protection of the mounting arm adapter Mounting arm tube Mounting arm tube for installation from below or above Side cover... -
Page 11: Interface Description
Product overview Interface description In the basic configuration, the panel PC includes the following interfaces: • Power supply (X101) • Ethernet (X102) The interfaces are located on the rear of the housing behind a cover. To access the interfaces, you must first remove the cover. -
Page 12: Power Supply
(X101). The cable is routed through the mounting arm adapter. If the panel PC is equipped with an integrated uninterruptible power supply (UPS), an external battery can additionally be connected to PIN 1 and PIN 2. The Beckhoff battery pack C9900-U330 is available for this purpose. 12 10 Fig. 3: Voltage socket pin numbering... -
Page 13: Ethernet Rj45
Product overview 3.2.2 Ethernet RJ45 The panel PC has an Ethernet RJ45 interface (X102) in the form of a push-pull Ethernet built-in socket. The Ethernet standards 100Base-T, 1000-Base-T and 2500Base-T enable the connection of corresponding network components and data rates of 100/1000/2500 Mbit/s. The required speed is selected automatically. The RJ45 connection technology with twisted-pair cables is used. -
Page 14: Table 6 Led Meaning Speed 100/1000 Mbit/S
Product overview Table 6: LED meaning speed 100/1000 Mbit/s Mbit/s Lights-up orange 1000 Lights up green Table 7: LED meaning speed 100/1000/2500 Mbit/s Mbit/s 1000 Lights-up orange 2500 Lights up green Version: 2.0 CP32xx... -
Page 15: Name Plate
Product overview Name plate The name plate provides information about the equipment of your device. The name plate shown here serves only as an example. Fig. 5: Name plate Table 8: Legend name plate Description Model: The last four digits indicate the device generation CP32xx Version: 2.0... - Page 16 Product overview Description Serial number (BTN) Date of manufacture Mainboard Main memory Display Touch screen SSD or CFast Power supply unit: 24 V MAC addresses of the Ethernet interfaces FCC approval Symbols Note: Here are the symbols applicable to the device such as CE, EAC, UKCA, .
-
Page 17: Commissioning
5. Brush away air bubbles towards the edge with a doctor blade or other object with a soft rubber or felt edge. ð The film is now fitted. You can use the Dimming, Screensaver and Cleaning mode functions with the Display Control Tool. The Beckhoff Information System provides more information about the tool: https: https://infosys.beckhoff.com/ content/1031/panelconfigurationtools/11725543179.html?id=7993182328699786200. CP32xx Version: 2.0... -
Page 18: Transport And Storage
Commissioning Transport and storage The specified storage conditions must be adhered to (see Technical data [} 48] chapter). Despite the robust design of the unit, the components are sensitive to strong vibrations and impacts. During transport the device must therefore be protected from mechanical stress. Appropriate packaging of the device, such as the original packaging, can improve the vibration resistance during transport. -
Page 19: Mounting
PC with a 48 mm circular tube. The permissible tolerance of the pipe diameter is -0.1 to +0.8 mm. Fig. 6: Mounting arm adapter Dimensions The dimensions of the panel PC can be found in the download finder on the Beckhoff website: https: // www.beckhoff.com/en-en/support/download-finder/search-result/?c-1=27833209&search=cp32xx All dimensions are in mm. CP32xx... -
Page 20: Mounting Arm Tube Installation
Among other tools you need a hook wrench for the installation. You can order this from your Beckhoff Sales using the following order identifier: •... -
Page 21: Installing A Toolboard And Handle
Toolboard for keyboard or tools, mounted on the underside of a Control Panel or a Panel PC CP3x12 to CP3x24, with integrated IP65 USB socket at the rear, can only be ordered together with the panel PC http://www.beckhoff.com/c9900-m406 C9900-M423 Toolboard for keyboard and mouse or tools, mounted on the underside of a... -
Page 22: Fig. 9 Toolboard Mounting Brackets
Commissioning Installing toolboard To mount a toolboard on the device, follow the steps below, which are shown in figures (9-11): 1. Screw the toolboard brackets to the bottom of the device using the three M5 screws. Fig. 9: Toolboard mounting brackets 2. -
Page 23: Fig. 11 Mounting Strain Relief
Commissioning Fig. 11: Mounting strain relief ð You have mounted the toolboard on the device. CP32xx Version: 2.0... -
Page 24: Connecting The Panel Pc
Commissioning Connecting the Panel PC CAUTION Risk of electric shock Dangerous touch voltages can lead to electric shock. To avoid electric shock, observe the following: • Never connect or disconnect the device cables during a thunderstorm. • Provide protective earthing for handling the device. To make the device ready for operation, you have to connect it. -
Page 25: Fig. 12 Grounding Bolt For Functional Earthing
Commissioning The functional earth is necessary for the EMC of the device. The functional earth is established via the connection of the grounding bolt in the connection section of the panel PC (see Fig. 12). Use cables with a minimum cross-section of 4 mm for the ground connection. -
Page 26: Connecting Cables And Power Supply
If you ordered your device with an integrated UPS, then you can connect an external battery pack and install it on a DIN rail near to the PC. Use only Beckhoff battery packs for this: Table 10: Order identifier battery pack... -
Page 27: Fig. 13 Wiring Diagram C9900-U330
24 V DC 24 V/3,4 Ah 30 V/9 A C9900-U330 battery pack Fig. 13: Wiring diagram C9900-U330 Further information on the battery pack can be found in the corresponding manual in the download finder on the Beckhoff website C9900-U330. CP32xx Version: 2.0... -
Page 28: Switching The Panel Pc On And Off
When you switch on the device for the first time, the optionally pre-installed operating system will be started. For any additional hardware you have connected, you have to install the drivers yourself afterwards. In addition, the Beckhoff Device Manager starts automatically. The Device Manager is a software from Beckhoff that supports you in configuring the device. - Page 29 The UPS software components with the corresponding drivers must be installed on the PC in order to operate the power supply unit as a UPS. The software components and drivers are already installed on delivery of the PC with operating system. If they are not, you have to install the installation package Beckhoff UPS yourself.
-
Page 30: Configuration
UPS. The Beckhoff Device Manager is a tool for detailed system diagnostics of hardware and software components. You will be shown the procedure for the first start of the Beckhoff Device Manager as well as for manual start. -
Page 31: Ups Configuration
Secure passwords Strong passwords are an important prerequisite for a secure system. Beckhoff supplies the device images with standard user names and standard passwords for the operating system. It is imperative that you change these. Controllers are shipped without a password in the UEFI/BIOS setup. Beckhoff recommends assigning a password here as well. -
Page 32: Fig. 16 Select Ups
Configuration Fig. 16: Select UPS 2. Select the manufacturer Beckhoff from the drop-down menu. Fig. 17: Select manufacturer 3. Select at Model/Interface Beckhoff P24Vxxxx. 4. Select the port COM4. 5. Click Finish. Fig. 18: Select model/interface & port 6. Click Apply. Version: 2.0... -
Page 33: Fig. 19 Apply Configuration
Configuration Fig. 19: Apply configuration ð You have configured the UPS. The status of the connected UPS is displayed. Fig. 20: UPS status CP32xx Version: 2.0... -
Page 34: Decommissioning
Decommissioning Decommissioning NOTICE Hardware damage due to power supply A connected power supply can cause damage to the device during disassembly. • Disconnect the power supply from the device before starting to disassemble it. As part of the decommissioning of the panel PC, you must first disconnect the power supply and cables. Afterwards, you can dismount the device from the mounting arm. -
Page 35: Disassembly And Disposal
Decommissioning Disassembly and disposal To be able to dismount the panel PC from the mounting arm, you must first have disconnected the power supply and the cables (see Chapter Disconnecting the power supply and cables [} 34]). Disassembly mounting arm tube NOTICE Damage to property due to falling down If the panel PC is suspended from the ceiling and you undo the cap nut of the mounting arm adapter... -
Page 36: Fig. 22 Disassembly Handle
Decommissioning Fig. 22: Disassembly handle Disassembly toolboard To remove a toolboard from the device, follow the steps shown in figures (23-25): 1. Loosen the two M4 screws of the strain relief. Fig. 23: Removing strain relief 2. Loosen the four M5 screws on the toolboard. Version: 2.0 CP32xx... -
Page 37: Fig. 24 Dismounting The Toolboard
Decommissioning Fig. 24: Dismounting the toolboard 3. Loosen the three M5 screws of the toolboard brackets. Fig. 25: Dismounting the toolboard brackets ð You have dismantled the toolboard. Disposal of the panel PC When disposing of the panel PC, be sure to observe the national electronic waste regulations. CP32xx Version: 2.0... -
Page 38: Maintenance
You can clean the front screen of the device during operation. In order to avoid inadvertent touch entries when doing this, you must first set the device to "Cleaning Mode" with the help of the Beckhoff Display Control Tool. Also make sure that you not only clean the display area, but also the edge of the glass pane. -
Page 39: Fig. 26 Select "Cleaning Mode
Maintenance The Beckhoff Display Control Tool does not start automatically when the device starts up. Proceed as follows to activate the "Cleaning Mode" of the tool: 1. Click the Beckhoff Display Control Tool icon to start it. ð When the tool is started, a small sun symbol appears in the taskbar. -
Page 40: Table 11 Device Component Replacement Recommendations
NOTICE Use of incorrect spare parts The use of spare parts not ordered from Beckhoff Service can lead to unsafe and faulty operation. • Only use spare parts that you have ordered from Beckhoff Service. Beckhoff devices are manufactured from components of the highest quality and robustness. They are selected and tested for best interoperability, long-term availability and reliable function under the specified environmental conditions. - Page 41 Maintenance If it is not possible to create an ESD protection zone, you can still protect the device against ESD damage. For example, the following measures can be used: • Use conductive mats connected to the ground potential as underlays. •...
-
Page 42: Access To Device Components
Maintenance 7.2.1 Access to device components To be able to replace the battery and the storage medium, you must first gain access to these device components. Follow the steps below: 1. Loosen the four M3 screws (1) at the marked points (section A). Make sure that the cover is secured against falling down. -
Page 43: Replacing The Storage Media
If you want to exchange a storage medium according to Beckhoff's recommendation, you must copy the data from the old to the new storage medium. You can use the Beckhoff Service Tool (BST) for this purpose. BST is a graphical backup and restore program for PCs with a Windows operating system. You can create an image of your operating system and use it to back up the operating system. -
Page 44: Fig. 30 Replacing The Cfast
Maintenance Fig. 30: Replacing the CFast 3. Insert the new CFast into the device in the same orientation until it protrudes just a bit from the device. The sticker with details of the CFast equipment must face outwards. 4. Press the CFast into the device. ð... -
Page 45: Replacing The Battery
Replace the battery with R/C (BBCV2), order number RC2032, nominal voltage 3 V. Using any other battery may cause fire or explosion. • Only replace the battery with a replacement battery from Beckhoff Service. • When replacing the battery, make sure that the polarity is correct. - Page 46 Maintenance Battery disposal To dispose of the battery, remove it, tape off the poles and put it in the battery disposal. Version: 2.0 CP32xx...
-
Page 47: Troubleshooting
No function of the panel PC No power supply to the panel PC Check the power supply cable Other cause Call Beckhoff Service The panel PC does not boot fully BIOS setup settings are incorrect Check BIOS setup settings (load... -
Page 48: Technical Data
CP3219: 10.2 kg CP3221: 10.7 kg CP3224: 11.7 kg Supply voltage 22-30 V (24 V power supply unit) Power consumption Data sheet power consumption and power loss in the download finder: https://www.beckhoff.com/en-en/support/download-finder/search- result/?download_group=691754572 Protection rating IP65 Vibration resistance (sinusoidal EN 60068-2-6: 10 ... 58 Hz: 0.035 mm vibration) 58 ... -
Page 49: 10 Appendix
33415 Verl Germany Phone: + 49 5246/963-0 email: info@beckhoff.de The addresses of the worldwide Beckhoff branches and agencies can be found on our website at http:// www.beckhoff.com/. You can also find further documentation for Beckhoff components there. CP32xx Version: 2.0... -
Page 50: Approvals
Appendix 10.2 Approvals Your device has at least the following approvals: • CE • EAC • UKCA • FCC You will find all other applicable approvals on the name plate of your device. FCC approvals for the United States of America FCC: Federal Communications Commission Radio Frequency Interference Statement This device was tested and complies with the limits for a digital device of class A, according part 15 of the FCC regulations. -
Page 51: List Of Figures
Mounting strain relief........................Fig. 12 Grounding bolt for functional earthing ..................Fig. 13 Wiring diagram C9900-U330......................Fig. 14 Beckhoff Device Manager - Change passwords ................Fig. 15 Beckhoff Device Manager – Start page ..................Fig. 16 Select UPS........................... Fig. 17 Select manufacturer ........................ - Page 52 List of tables List of tables Table 1 Legend structure .......................... Table 2 Wiring with 8-core cable....................... Table 3 Wiring with 12-core cable (C9900-K275/-K276/-K277) ..............Table 4 Controller classification based on device generation ..............Table 5 Ethernet interface pin assignment....................Table 6 LED meaning speed 100/1000 Mbit/s ..................
- Page 54 More Information: www.beckhoff.com/cp32xx Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
