User Manual
VEX-B24A
Version: 1.0
Due to the regular upgrades of systems and products, ZKTeco could not guarantee exact
consistency between the actual product and the written information in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEX-B24A and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco VEX-B24A

  • Page 1 User Manual VEX-B24A Version: 1.0 Due to the regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
  • Page 2 REMARK Please follow the user manual for correct installation and testing. If there is any doubt please call our tech-supporting and customer center. Our company applies ourselves to reformation and innovation of our products. No extra notice for any change. The illustration shown here is only for reference. If there is any difference, please take the actual product as the standard.
  • Page 3: Table Of Contents

    CATALOG PRODUCT FEATURE ..............- 1 - TECHNICAL PARAMETER ............- 1 - PACKAGE CONTENT ..............- 2 - OVERVIEW .................. - 3 - BASIC OPERATION ..............- 4 - DEVICE SETTING ............... - 5 - WEB SETTING ................- 9 - SYSTEM DIAGRAM ..............
  • Page 4: Product Feature

    PRODUCT FEATURE 1. Induction loop for hearing impaired 2. Braille dot for visually impaired 3. 3 output relays for door locks 4. Tamper alarm 5. Facial Recognition (No distortion) 6. Support Face, IC (13.56MHz) & ID (125kHz) card, PIN code 7.
  • Page 5: Package Content

    PACKAGE CONTENT MODEL: VEX-B24A (Surface Mounting) Sealing Plug of VEX-B24A Wiring Cover Junction Pressing PWM3×8×7 (4 pcs) Wiring Port Screw Fixing Seat (4 Rear Cover PA4×25 (4 pcs) FM3×4.5 (2 pcs) Hang rope pcs) Wrench Screw Diode (3 pcs) Rain Hood (Optional)
  • Page 6: Overview

    OVERVIEW - 3 -...
  • Page 7: Basic Operation

    BASIC OPERATION 1. Call and Monitor 1.1 Call Indoor Monitor In standby mode, press room numbers + #/dial on Door Station to call Indoor Monitor. During the call, press * on Door Station again to end the call. If the call fails or Indoor Monitor is busy, Door Station will make a beep sound.
  • Page 8: Device Setting

    DEVICE SETTING Connect Door Station and PC to a network switch in the same LAN. You can enter the admin settings of Door Station by pressing # twice and entering default password (123456). This is where you can configure the device. 1.
  • Page 9 × 720); Password: Administrator password of the Device (Default 123456); 2. Network Settings The device network can be set to either DHCP or a static IP address. CMS parameters should be configured here when you try to register this device to CMS. DHCP: Enable DHCP (Dynamic Host Configuration Protocol) to dynamically distributing network...
  • Page 10 3.1 Face Settings Delete All: Press 1 + # to delete all face info; 3.2 Password Settings Add: Press # to add PIN code for different relays; Delete: Press PIN code to delete PIN code under this room number; Delete All: Press 1 + # to delete all PIN codes;...
  • Page 11 3.4 Settings Recognizer: Enable to use face recognition; Similarity: Sensitivity of facial similarity analyzer (Low, normal, high); Live Detect: Sensitivity of live detect to prevent picture fraud or video fraud (Close, normal, high); Unlock Time: The length of unlock time (1-9s); Unlock Delay: The length of unlock delay time (1-9s);...
  • Page 12: Web Setting

    WEB SETTING Connect Door Station and PC to a network switch in the same LAN. You can enter the IP address of Door Station in the web browser search bar and log in with the default account (admin) and password (123456). This is where you can configure the device. For getting the IP address, you can search by Remote Upgrade Tool which is installed in the same LAN with the devices.
  • Page 13 Model: Model of the device; Firmware Version: Firmware version of the device; MAC Address: MAC address of the device; Framework: Framework of the device; UI of the device; MCU: MCU of the device; DHCP: Status of DHCP; IP Address: Current IP address of the device; Mask: Subnet mask of the device;...
  • Page 14 Language: 16 languages supported (简体中文, English, 繁體中 文, ‫ ,ﬠִ בר ִ ית‬Deutsch, Español, Türk, Tiếng Việt, Nederlands, Português, Polski, Русский, ‫,ﻋرﺑﻲ‬ Français, Italiano, slovenský); Resolution: 3 resolutions supported (320 × 240, 640 × 480, 1280 × 720); Intercom: Volume of Intercom can be set from 1 to 6; System: Volume of System can be set from 1 to 6;...
  • Page 15 System Old Password: Current administrator password of the Device (Default 123456); System New Password: New administrator password of the Device; System Confirm Password: Confirm administrator password of the Device; Web Old Password: Current administrator password of the web (Default 123456); Web New Password: New administrator password of the web;...
  • Page 16 Backup&Restore: Backup all setting and restore settings; Upgrade: Upgrade equipment; Reset: Reset to factory settings; Reboot: Reboot the device; Packet Capture: Capturing packets can help developers reproduce positioning problems; Logs: Device logs; Screenshot: Screenshot device interface; 2. Intercom 2.1 Intercom > Device Numbers here are basic settings for making a call to Indoor Monitor.
  • Page 17 Mode: Mode for apt. and wall (Unit and wall); Building: Number of the building (Range: 1-999); Unit: Number of the unit (Range: 1-99); Index: Number of the device (Range: 1-9); 2.2 Intercom > Network The device network can be set to either DHCP or a static IP address. CMS parameters should be configured here when you try to register this device to CMS.
  • Page 18 IP Address: Configure Static IP address to manually distribute network configuration parameters; Mask: Subnet mask; Gateway: A component that is part of two networks, which use different protocols; DNS: Domain Name Server of the device; CMS: Enable to use CMS software to manage devices; CMS IP: Server address of CMS;...
  • Page 19 2.4 Intercom > Ring Group Ring group is for setting up SIP calls or call mode. Concierge button, the length of the call and ring time can also be configured here. Mode: 2 modes supported (one by one, all at once); Call Concierge URL: Fill in the call destination for concierge button or the single button on the device;...
  • Page 20 Search: Fill in text inputs to search; Reset: Click reset to clear words in text inputs; Delete All: Delete all data on the chart; Import: Import all data to the chart; Export: Export all data on the chart; 3. Access 3.1 Access >...
  • Page 21 Relay2:0, relay3: *); Unlock Delay: The length of unlock delay time (1-9s); Unlock Time: The length of unlock time (1-9s); Dry Contact Input 1-3: 3 modes of dry contact inputs are supported (Exit Button, Door Sensor, Fire Linkage); Lift Reference Floor: The floor Door Station is installed at (Range: -9-99);...
  • Page 22 4. Advanced 4.1 Advanced > Video Real-time video from IP cameras can be obtained by filling in its URL (RTSP). On the talking interface of Indoor Monitor, you can click the little keyboard icon to switch to IP cameras’ video. (No.1 on the keyboard stands for Door Station while No.2 to No.5 stands for IP camera) RTSP Feed: 4 IP cameras supported to switch while talking on...
  • Page 23 4.2 Advanced > More More column is for Tamper Alarm and ONU Penetration. Advertise: Enable to advertise on the screen saver of the device; URL: Advertise URL; Time (minutes): The time length of advertise display (10mins, 20mins, 30mins); Tamper Alarm: Enable to use Tamper alarm;...
  • Page 24: System Diagram

    SYSTEM DIAGRAM - 21 -...
  • Page 25: Device Wiring

    DEVICE WIRING 1. Network (PoE) Standard RJ45 interface is for the connection with PoE+ switch or other network switch. PSE shall comply with IEEE 802.3at (PoE+) and its output power not less than 30W and its output voltage not be less than 50V. 2.
  • Page 26 4. RS485/Switching Value Output Enable to connect equipment with RS485 interface. Connect to the lock module (an independent power supply is necessary for the lock). Warning! 1. When connecting to an inductive load device such as a relay or electromagnetic lock, you are recommended to use a diode 1A/400V (included in the accessories) in anti-parallel with the load device to absorb inductive load voltage peaks.
  • Page 27: Installation

    INSTALLATION Surface Mounting-Asian Gang Box Asian Gang Box Product size: 133 × 295 × 41 mm Surface Mounting size: 133 × 295 × 43 mm - 24 -...
  • Page 28 Flush Mounting Product size: 133 × 295 × 41 mm Flush Mounting size: 133 × 295 × 63.5 mm Mounting hole size: 124 × 289 × 56 mm - 25 -...
  • Page 29 Surface Mounting & Rain Hood (Optional) Asian Gang Box Product size: 133 × 295 × 41 mm Surface Mounting size: 133 × 295 × 43 mm - 26 -...
  • Page 30 Flush Mounting & Rain Hood (Optional) Product size: 133 × 295 × 41 mm Flush Mounting size: 133 × 295 × 63.5 mm Mounting hole size: 124 × 289 × 56 mm - 27 -...
  • Page 31 Tips: The camera should be 1450~1550mm above the ground. The camera at this height can capture human face perfectly. - 28 -...
  • Page 32: Troubleshooting

    TROUBLESHOOTING The Indoor Monitor cannot start up or power off automatically. Check whether it has power-failure, and power it on again  The Indoor Monitor display screen is too dim. Check whether the brightness and contrast settings of screen are correct. ...
  • Page 33: Safety Instruction

    SAFETY INSTRUCTION In order to protect you and others from harm or your device from damage, please read the following information before using the device. Do not install the device in the following places:  Do not install the device in high-temperature and moist environment or the area close to ...
  • Page 34 FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 35 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
