Medium Back Executive Office Chair
MODEL RTA-4907
ASSEMBLY INSTRUCTIONS
Do a quick inventory
of all the parts and
hardware listed below.
A
B
Backrest
F
G-L
Casters
x5
HARDWARE LIST
Part # QTY SIZE/Description
I
12
M6x20
J
8
Hole covers
technimobili.com
RTA-4907
REV.4-HGO-8595-1224
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
support@rtaproducts.com
MAIN PARTS LIST
C
Seat
5-Leg star base
Left armrest
(Front)
Item
mm 10 20 30 40
Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.
D
Mechanism
G-R
Right armrest
(Front)
INCLUDED TOOLS
Allen Wrench
support@rtaproducts.com
P.1
Thank you for
purchasing our product!
E
Lift cylinder
H
Covers for lift
cylinder
x1
Set
Advertisement
Related Manuals for Techni Mobili RTA-4907
Summary of Contents for Techni Mobili RTA-4907
- Page 1 RTA-4907 Medium Back Executive Office Chair MODEL RTA-4907 ASSEMBLY INSTRUCTIONS REV.4-HGO-8595-1224 Thank you for purchasing our product! For Support, assembly questions Replacement Parts for International Do a quick inventory & Replacement Parts within the Customers & AK-HI-PR orders: of all the parts and...
- Page 2 RTA-4907 ASSEMBLY STEPS STEP 1 FIRST: Attach F to THEN: Insert E in C using pressure. the middle of C and covered it with H. STEP 2 Assemble D to B with screws I, and with its tension knob facing towards the front.
- Page 3 RTA-4907 ASSEMBLY STEPS STEP 4 Assemble the armrests G-L and G-R to the seat B in their respective sides with screws I, but LEAVE THEM LOOSE to allow flexibility for step 5. LEFT DO NOT TIGHTEN! RIGHT DO NOT TIGHTEN!
- Page 4 RTA-4907 CHAIR'S FUNCTIONS HEIGHT Pull Handle UP. TENSION Turn CLOCKWISE for less tension (-); TILTING Pull Handle OUT COUTERCLOCKWISE to UNLOCK; for more tension (+). Push Handle IN With less tension, the tilting feels easier. to LOCK. WARNINGS - Not paying attention to the following warnings could result in injuries.
