Kramer TBUS-100XL Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
TBUS-100XL Round Table Connection Bus
Step 2: Get to know your TBUS-100XL
# Feature
1 Pneumatic Mechanism
2 Outer Rim
3 Mounting Screws (x2)
4 Locking Butterfly Nuts (x2)
5 Mounting Butterfly Nuts (x2)
6 Mounting Brackets (x2)
7 Black Anodized or Brushed Aluminum
Semi-Automatic Lid (with Opening for
Cable Pass-Through)
8 Lid Latch
9 Lock for latch
10 Pass-Through Opening and Bushing
(x5)
11 Frame Screws (x8)
TBUS-100XL Quick Start
TBUS-100XL Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/TBUS-100XL
firmware upgrades are available.
W
Function
Enables automatic lifting and smooth closing of the lid.
Fits over the table surface.
For securing
Tighten to lock the mounting butterfly screw.
Tighten to secure the unit to the table surface.
For securing the unit to the table surface.
Covers the connecting surface, leaving the table surface neat and tidy.
For safely closing the lid.
To secure lid.
Insert a cable through the opening and the bushing (inner diameter approx. 10mm
Ø).
For securing and adjusting the height of the frame.
TBUS-100XL for the first time.
to download the latest user manual and check if
1 Quick start guide
In the graphic,
enclosure for a better view of the frame.
TBUS-100XL to the table.
P/N: 2 9 0 0 - 3 0 1 5 4 8 QS
Table cutout template
TBUS-100XL is shown without its
Rev: 1
