- Page 1 USER MANUAL MODEL: TBUS-100XL Table Connection Bus P/N: 2900-301554 Rev 1 www.kramerAV.com...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Introduction Getting Started Overview TBUS-100XL Table Connection Bus Installing the TBUS-100XL Cutting a Hole in the Table Connecting the Cables Mounting the TBUS-100XL in the Table Using the TBUS-100XL Technical Specifications TBUS-100XL – Contents... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we... -
Page 4: Overview
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/il/quality/environment. -
Page 5: Tbus-100Xl Table Connection Bus
Enables automatic lifting and smooth closing of the lid. Outer Rim Fits over the table surface. Mounting Screws (x2) For securing TBUS-100XL to the table. Locking Butterfly Nuts (x2) Tighten to lock the mounting butterfly screw. Mounting Butterfly Nuts (x2) Tighten to secure the unit to the table surface. -
Page 6: Installing The Tbus-100Xl
1. Cut a 104mm X 97mm (5.4” to 5.5”) hole in the table in the desired location. The thickness of the table should be 3” (76mm) or less. 2. Clean the table surface. Take care not to damage the table. Kramer AV is not responsible for any damage caused to the table. Connecting the Cables... - Page 7 Kramer Electronics Ltd. 2. Insert a cable into an opening and place the bushing around the cable. 3. Push the bushing into the pass- through opening to secure. TBUS-100XL – Installing the TBUS-100XL...
-
Page 8: Mounting The Tbus-100Xl In The Table
Kramer Electronics Ltd. Mounting the TBUS-100XL in the Table To mount the unit: 1. Before mounting the TBUS-100XL, pass the cables through the unit. Insert the TBUS-100XL into the hole cut into the table making sure the outer rim is firm against the surface of the table. -
Page 9: Using The Tbus-100Xl
Using the TBUS-100XL Once the TBUS-100XL is installed, you can easily customize it to your own needs by directly plugging in the required AV equipment, as illustrated in the example in Figure Figure 3: TBUS-100XL Boardroom Installation TBUS-100XL – Using the TBUS-100XL... -
Page 10: Technical Specifications
15.5cm x 14.6cmm (6.1" x 5.7") Shipping Dimensions (W, D, H) 27.5cm x 22cm x 19.5cm (10.8" x 8.7" x 7.7") Net Weight 1.32kg (2.9lbs) approx. Shipping Weight 1.9kg (4.2lbs) approx. Specifications are subject to change without notice at www.kramerav.com TBUS-100XL – Technical Specifications... - Page 11 This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
