Enter the VLAN index in the "VLAN" edit box then press "Go to"
button
You can add, edit and remove port members of each VLAN and then
finally press "Apply" button only once to configure the desired
VLANs you want.
Note: if you want to set multiple VLANs, we suggest that you set
Default VLAN ID for each port first in Ports page.
Trunk
Port trunking is the ability to group several 10/100Base-TX or
100Base-FX ports to increase the bandwidth between this switch
and another compatible switch. This is an inexpensive way to
increase bandwidth. We define port trunking as the ability to group
set of ports (up to 8) within the same module into a single logical link.
The port trunk acts as a single link between switches. Multiple trunks
may be implemented in this switch, but only one trunk can be
created within a module.
You can add, edit and remove port members of each trunk and then
press "Apply" button after you have finished configuring the trunks
you need.
Figure 5-7 The Trunk page
41
