EVAL_XDPP1140_1148_DB evaluation board

user guide

About this document

Scope and purpose

This user guide explains how to set up the hardware and serves as a user manual for the

EVAL_XDPP1140_1148_DB

daughterboard. XDP™ XDPP1140-100B and XDP™ XDPP1148-100B belong to

Infineon's XDP™ digital power controller family, optimized to provide a high level of performance and design

flexibility for DC-DC converters. This controller is designed to achieve high efficiency, system control, and cost

savings for applications such as telecom, server, data centers, and computing DC-DC solutions. The daughter

board is designed to be used as a test and firmware development tool for XDPP1140 and XDPP1148. This

document describes the configuration of various jumper pins based on the device, features, and applications.

Intended audience

This document is intended for power supply design engineers, system engineers, and embedded power

designers.

Evaluation Board

This board is to be used during the design-in process for evaluating and measuring characteristic curves, and

for checking datasheet specifications.

Note:

PCB and auxiliary circuits are NOT optimized for final customer design.

User guide

Please read the sections "Important notice" and "Warnings" at the end of this document

V 1.0

www.infineon.com

2024-10-10

Table of Contents

Need help?

Do you have a question about the EVAL XDPP1140 1148 DB and is the answer not in the manual?

Questions and answers
