- Page 1 Quick Start Guide Quantim Coriolis Mass Flow Controllers ® & Meters (QmC) Coriolis Mass Flow This Quick Start Guide applies to QmC IP40, IP66 and Class 1 Div 2 / Zone 2 Controllers and Meters Beyond Measure...
- Page 2 Step 2: Mounting the Quantim Step 1: Location/Orientation The instrument may be located anywhere in the process line, as long as the following conditions are met: • Before operation, you must be able to stop flow through the meter. During the zeroing procedure, flow must be stopped completely, and the flow meter sensor tube must be full of process fluid to achieve an accurate zero. • During operation, the flow sensor tube must be full of process fluid. • Ambient temperature must remain between 0° and 60°C (32°F and 140°F).
- Page 3 Step 3B: Electrical Connections Step 3A: Electrical Connections Meter/Controller IP40 Meter/Controller IP66 or Class 1 Division 2 / Zone 2 D-Connector Functions Legends: 3-B1 • = Feature Available = Not Available NOTE: Chassis ground is available through the D-Connector back shell. 3-A1 D-Connector for QmC IP40 Pin Out Connections...
- Page 4 Tel (215) 362 3700 Fax (215) 362 3745 BrooksAm@BrooksInstrument.com A list of all Brooks Instrument locations and contact details can be found at www.BrooksInstrument.com Brooks and Quantim are trademarks of Brooks Instrument, LLC. All other trademarks are property of their respective owners.
