CUT series
(Roto Blade)
3, 5, 7.5 & 10 HP
barmesapumps
@ 1750 RPM
IMPORTANT! - Read all instructions in this manual before operating or servicing
a pump.
North America: 866 777 6060
Int'l: +1 267 404 2910
Installation, Operation &
Maintenance Manual
Submersible Sewage Pumps
with Cutter Blade
Springer Pumps
Springer Parts
Last update: SEP/15/2023
www.springerpumps.com
www.springerparts.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Barmesa Pumps CUT Series
Summary of Contents for Barmesa Pumps CUT Series
- Page 1 Installation, Operation & Maintenance Manual Submersible Sewage Pumps with Cutter Blade CUT series (Roto Blade) 3, 5, 7.5 & 10 HP barmesapumps @ 1750 RPM IMPORTANT! - Read all instructions in this manual before operating or servicing a pump. Last update: SEP/15/2023...
-
Page 2: General Safety Information
T h i s p u m p i s n o t medications, flammable material, oil or i n t e n d e d f o r u s e i n IMPORTANT! - Barmesa Pumps is not grease, strong chemicals, gasoline. swimming pools or water... -
Page 3: Specifications
Specifications DISCHARGE: 4" flange, horizontal. LIQUID TEMPERATURE: 104 °F (40 °C) max. VOLUTE: Cast iron ASTM A-48 class 30. MOTOR HOUSING: Cast iron ASTM A-48 class 30. IMPELLER: Cast iron ASTM A-48 class 30. SUCTION PLATE: Ductile iron ASTM A536 100-70-03. SHAFT: AISI 410 stainless steel (3 HP), AISI 420 stainless steel (5, 7.5 &... -
Page 4: Installation
Installation 4Receiving inspection Cable: 3. If there is a flow of liquid inside Upon receiving the pump, it should WARNING c) Never let the end of the tank, support the piping the cable contact water. inspected damage where appropriate. Install piping d) If the cable is extended, do not shortages. -
Page 5: Operation And Maintenance
Operation & Maintenance (Black) White Overload (Grey) protector Black (Brown) Green Frame grounding Black (Yellow/ Thermostat Green) Black switch (Green/Yellow) Leakage Ground White sensor Figure 2 4 Before Starting the Pump Daily inspections: Inspections at 3-5 year intervals: 1) After completing installation, 1) Check current and ammeter Conduct an overhaul of the pump. - Page 6 Operation & Maintenance 4Maintenance option 4Installing the QL-100 WARNING Be sure to cut off power Every cutter pumps is equipped with Remove both hex bolts and use the source before disassembly. multiple suction plate gaskets. M12 x 30 hex bolt to assemble back Throughout a period of time, the the suction plate to the volute.
- Page 7 Drawings 4CUT303 / 304 barmesapumps PUMP ELBOW C.W.L.: Continuous Running Water Level VOLUTE CONNECTION L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) PIPE CONECTION TYPE 27.8 15.8 10.2 16.1 35.8 27.6 11.5 14.4 - Dimensions in inches. - Weight in pounds, without the cable.
- Page 8 Drawings 4Slide Rail Coupling QL-100 for CUT303 / 304 barmesapumps C.W.L.: Continuous Running Water Level L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) PIPE CONECTION TYPE 35.9 25.5 26.2 12.6 - Dimensions in inches. - Weight in pounds, without the cable. - WT1: coupling weight.
- Page 9 Drawings 4CUT503 / 504 barmesapumps C.W.L.: Continuous Running Water Level PIPE CONECTION TYPE L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) 24.4 13.7 13.3 28.8 10.8 12.3 - Dimensions in inches. - Weight in pounds, without the cable. North America: 866 777 6060 Springer Pumps www.springerpumps.com...
- Page 10 Drawings 4Slide Rail Coupling QL-100 for CUT503 / 504 barmesapumps PIPE CONECTION TYPE C.W.L.: Continuous Running Water Level L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) 35.9 25.4 13.3 31.5 29.7 13.5 - Dimensions in inches. - Weight in pounds, without the cable.
- Page 11 Drawings 4CUT753 / 754 barmesapumps 7.08 9.05 C.W.L.: Continuous Running Water Level PIPE CONECTION TYPE L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) 27.8 15.8 10.2 16.1 35.8 27.6 11.5 14.4 - Dimensions in inches. - Weight in pounds, without the cable.
- Page 12 Drawings 4Slide Rail Coupling QL-100 for CUT753 / 754 barmesapumps PIPE CONECTION TYPE NOTE: Remove pump feet for QL-100 installation C.W.L.: Continuous Running Water Level L.W.L.: Lowest Running Water Level QL-100 39.4 27.4 15.5 36.5 28.2 12.1 - Dimensions in inches. - Weight in pounds, without the cable.
- Page 13 Drawings 4CUT1003 / 1004 barmesapumps C.W.L.: Continuous Running Water Level PIPE CONECTION TYPE L.W.L.: Lowest Running Water Level (Most effective motor heat dissipation when fully submerged) 27.8 15.8 10.2 16.1 37.5 29.3 11.5 14.4 - Dimensions in inches. - Weight in pounds, without the cable. North America: 866 777 6060 Springer Pumps www.springerpumps.com...
- Page 14 Drawings 4Slide Rail Coupling QL-100 for CUT1003 / 1004 14.06 8.46 0.71 21.5 9.29 5.90 2.36 0.59 barmesapumps 0.75 C.W.L. 3.54 4.33 6.10 1.50 9.65 L.W.L. D4 P.C.D. D6 P.C.D. COUPLER COUPLER DISCHARGE CONNECTION CONNECTION 2.17 3.45 6.30 NOTE: Remove pump feet for QL-100 installation PIPE CONECTION TYPE C.W.L.: Continuous Running Water Level L.W.L.: Lowest Running Water Level...
-
Page 15: Repair Parts
Repair Parts 4CUT303 / 304 barmesapumps 13-1 13-2 For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List. North America: 866 777 6060 Springer Pumps www.springerpumps.com Int'l: +1 267 404 2910 Springer Parts... -
Page 16: Parts List
Parts List 4CUT303 / 304 ITEM DESCRIPTION MATERIAL Cable STOW Sensor cable SJTOW Motor cover ASTM A48 class 30 Motor housing ASTM A48 class 30 Oil chamber ASTM A48 class 30 Volute ASTM A48 class 30 Impeller ASTM A48 class 30 Suction plate ASTM A536 100-70-03 Pump feet... - Page 17 Repair Parts 4CUT503 / 504 barmesapumps 13-1 13-2 For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List. North America: 866 777 6060 Springer Pumps www.springerpumps.com Int'l: +1 267 404 2910 Springer Parts...
- Page 18 Parts List 4CUT503 / 504 ITEM DESCRIPTION MATERIAL Cable STOW Sensor cable SJTOW Motor cover ASTM A48 class 30 Motor housing ASTM A48 class 30 Oil chamber ASTM A48 class 30 Volute ASTM A48 class 30 Impeller ASTM A48 class 30 Suction plate ASTM A536 100-70-03 Pump feet...
- Page 19 Repair Parts 4CUT753 / 754 23-1 34-1 barmesapumps 13-1 13-2 For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List. North America: 866 777 6060 Springer Pumps www.springerpumps.com Int'l: +1 267 404 2910...
- Page 20 Repair Parts 4CUT753 / 754 ITEM DESCRIPTION MATERIAL Cable STOW Sensor cable SJTOW Motor cover ASTM A48 class 30 Motor housing ASTM A48 class 30 Oil chamber ASTM A48 class 30 Seal bracket ASTM A48 class 30 Volute ASTM A48 class 30 Impeller ASTM A48 class 30 Suction plate...
- Page 21 Repair Parts 4CUT1003 / 1004 23-1 34-1 barmesapumps 13-1 13-2 For repair part please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List. North America: 866 777 6060 Springer Pumps www.springerpumps.com Int'l: +1 267 404 2910...
- Page 22 Repair Parts 4CUT1003 / 1004 ITEM DESCRIPTION MATERIAL Cable STOW Sensor cable SJTOW Motor cover ASTM A48 class 30 Motor housing ASTM A48 class 30 Oil chamber ASTM A48 class 30 Seal bracket ASTM A48 class 30 Volute ASTM A48 class 30 Impeller ASTM A48 class 30 Suction plate...
- Page 23 (4)Strainer is closed too far. (4) Open strainer. NOTE: Barmesa Pumps assumes no responsibility for damage or injury due to disassembly in the field. Disassembly of the pumps or supplied accessories other than at Barmesa Pumps or its authorized service centers, automatically voids warranty.
- Page 24 BARMESA PUMPS FACTORY WARRANTY Barmesa Pumps warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for 18 months from date of manufacture or 12 months from installation date whichever occurs first. This warranty gives you specific legal rights, which vary from state to state.
