- Page 1 Installation, Operation & Maintenance Manual Submersible Solids Handling Pumps 4BSE-HLDS 7.5, 11.3, 15 HP @ 1750 RPM barmesapumps.com IMPORTANT! - Read all instructions in this manual before operating or servicing a pump.
-
Page 2: General Safety Information
IMPORTANT! - Barmesa Pumps is not systems, that are required to reduce installations where there is responsible for losses, injury or the potencial for property damage. -
Page 3: Specifications And Dimensions
Specifications & Dimensions DISCHARGE: 4", 125lb, flange horizontal. SPHERICAL SLD HNDLG: 3" LIQUID TEMPERATURE: 104° F (40° C) max. Cast iron ASTM A-48 class 30. VOLUTE: Cast iron ASTM A-48 class 30. MOTOR HOUSING: Cast iron ASTM A-48 class 30. SEAL PLATE: 2 vane, closed, with vanes on back side. -
Page 4: Recommendations And Warnings
Recommendations and Warnings Receiving inspection Installation Liquid Level Controls Upon receiving the pump, it should These pumps are recommended for The level control(s) should be inspected damage use in a sump, basin or lift station. mounted on the discharge piping, a shortages. -
Page 5: Installation & Service
Installation & Service Overload Protection: If current through the temperature Kickback should always be in a Three Phase - The Normally Closed sensor exceeds the values listed, an counter-clockwise direction intermediate control circuit relay viewed from motor end or opposite (N/C) thermal sensor is embedded in the motor windings and will detect must be used to reduce the current... - Page 6 Service Servicing If oil is found to be dirty or Use soap solution around the sealed Ÿ NOTE: Item numbers in ( ) refer to contaminated (or measures below areas above the oil level and inspect Figures 6. 15 kV breakdown), the pump must joints for "air bubbles".
- Page 7 Service Disassembly Motor and Bearings - Remove Apply adhesive compound to the Impeller and Volute - Disconnect volute, impeller, seal plate and seal as shaft and press bearing (14) onto power. Remove hex nuts (26) and shaft, position squarely onto the previously stated and drain oil from vertically lift motor housing and seal motor housing (3).
- Page 8 Service Motor end Thread cap screws (25) into bearing housing (16) and tighten. Refill Bearing chamber with oil. Housing (16) Conduit Box Assembly - Check Moisture sensor power (35) and control cables (36) for probe (38) Seal stationary crackes or damage and replace complete conduit box (4) if required.
- Page 9 Service Impeller and Volute - Install impeller (29) by appling a thin film of oil to motor shaft and slide impeller straight onto shaft, keeping keyways lined up. Drive key (13) into keyway. Locate washer, apply thread lock primer (such as Loctite® Primer T), let set per manufacturer's directions.
- Page 10 Repair Parts Figure 6 barmesapumps.com For Repair Part Please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List.
- Page 11 Parts List barmesapumps.com 91010433 91010433 1 1 1 03140078C 03140078C For Repair Part Please supply: Model Number and Serial as shown on Name Plate, and Part Description and Part Number as shown on Parts List.
-
Page 12: Troubleshooting Chart
13. Piping attachments to building structure too loose or rigid NOTE: Barmesa Pumps assumes no responsibility for damage or injury due to disassembly in the field. Disassembly of the pumps or supplied accessories other than at Barmesa Pumps or its authorized service centers, automatically voids warranty.
