Loading and Using the ICC Profile
Once the profile has been generated, follow the steps below to use the ICC
profile you just created.
1. Restart ScanWizard-One and open the Scan Settings interface (TWAIN
2
3. Go to the "Image Processing"
4. Go to the "Scanner Settings"
Aligning the Registration Marks
A. Upper-left registration mark
Move the cursor to the target
image area; the pointer will
change to a horizontally flipped L
mark (" ").
Align the cursor with the small
upper-left registration mark.
interface).
Select the type of material to scan in the Material drop-down list:
Select "Reflective" to scan reflective materials or "Positive Film" for
transparencies and slides.
panel and select "Default" as
Configuration option to return
to the setting mode for general
objects scanning.
panel and select the ICC color
profile you loaded from the
Scanner Profile drop-down list.
Once loaded, you can begin
scanning your objects.
B. Upper-right registration mark
After the upper left mark is
aligned, the upper right part of
the target image is displayed, and
an instruction dialog box prompts
you to align the upper right
registration mark.
Move the cursor to the target
image area; the pointer will
change to a normal L mark (" ").
Align the cursor with the small
upper-right registration mark.
C. Bottom-right registration mark
After the upper right mark is
aligned, the lower right part of
the target image is displayed, and
an instruction dialog box prompts
you to align the bottom-right
registration mark.
Move the cursor to the target
image area; the pointer will
change to a vertically flipped L
mark (" ").
Align the cursor with the small
bottom-right registration mark.
