- Page 1 User manual FT-24FC Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels …………………………………………………………………………………6-9 ………………………………………………………………………………………10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu 1. Display screen 2. Menu key 3. Confirm key 4. Up key 5. Down key 6. Signal input 7. Power input 8. Signal output 9. Power output Main menu Submenu Options Default Instruction Address DMX address 1->512 Adjust DMX address Setting Feature Settings... -
Page 6: Dmx Channels
Used to save and load user User configuration 1 Load/Save Load configuration 1 Used to save and load user User configuration 2 Load/Save Load configuration 2 Manual control Channel control Channel control function Reset Execute Reset function Information Show the short name of the current Device name F75FT query... - Page 7 0->3 NONE Color temperature 2500K Color temperature 3200K Color temperature 4500K Color temperature 5600K Color temperature 6500K Color temperature 8000K 10->255 Color temperature adjusted from 10000K to 2500K 0->27 NONE 28->127 Color Macros 128->255 NONE 0->5 Open 6->10 On (dimming transition off) 11->105 Standard strobe (0~20Hz) 106->110...
- Page 8 10CH Channel Value Function 000-255 Main brightness Dimmer Fine 000-255 000-255 Red Adjustment 000-255 Green Adjustment 000-255 Blue Adjustment 000-255 White Adjustment No function Color temperature 2500K Color temperature 3200K Color temperature 4500K Color temperature 5600K Color temperature 6500K Color temperature 8000K 10-255 Color temperature adjusted from 10000K to 2500K 0->27...
- Page 9 12CH Channel Value Function 0->255 Dimmer 0->255 Dimmer Fine 0->255 Red Adjustment 0->255 Green Adjustment 0->255 Blue Adjustment 0->255 White Adjustment 0->255 Red Adjustment 0->255 Green Adjustment 0->255 Blue Adjustment 0->255 White Adjustment 0->5 Open 6->10 On (dimming transition off) 11->105 Standard strobe (0~20Hz) 106->110...
- Page 10 5.Dimension...
-
Page 11: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
