Summary of Contents for Uplus Lighting FP600
- Page 1 User manual FP600 Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Panel ……………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6 Trouble Shooting…………………………………………………………………………………7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
- Page 4 2.Technical Specifications Lamp: LED 600W lamp beads use imported chips life up to 50000 hours (One-button control the power is off and on ,suggest that the interval should be more than 10 seconds ) Color Temperature: 3200K / 4500K / 6500K Power Consumption: 700 W Power Voltage: AC 100-240V, 50/60Hz Color: Five colors + white (Red, Orange, Yellow, Blue, White)
- Page 5 3.Control Panel Control Panel: 1) Power switch; 2) Power connector; 3) OLED display; 4) Fader block to control the CRT wheel, iris, dimmer, stroboscope; 5) Color selection buttons; 6) Button on / off the light source; 7) XLR connectors, for controlling the spotlight via DMX.
- Page 6 4.DMX Channels Control mode: When a DMX signal is input, the DMX control mode takes precedence; OLED display displays DMX channel address Channels Function Value IRIS 0--255 Dimming 0--255 0-9 disabled Strobe 10-255 slow to fast 0-9 white 10-49 red 1 Color 50-99 yellow 2 00-149 blue 3...
- Page 7 5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
