Adding/Deleting Amy 2 Modes Io - SOMFY Amy 2 Modes io Instructions Manual

Amy 2 Modes io
2] To select another control mode and/or to activate/deactivate Low Power mode:
Press the channel selector to select the channel to modify. Only one channel can be modified at a time.
Briefly press once or several times in succession the Mode button to select the desired mode.
Number of short presses
Briefly press 1 time
Briefly press 2 times
Briefly press 3 times
Briefly press 4 times
Briefly press 5 times
Briefly press 6 times
Briefly press 7 times
Briefly press 8 times

2.3.Adding/Deleting Amy 2 Modes io

NOTICE
To program the first control point, refer to the instructions for the io drive or receiver.
The procedures for adding or deleting Amy 2 Modes io are the same.
NOTICE
• It is advisable to do next steps with front panel buttons deactivated to avoid sending unwanted commands by
manipulating the module (refer to Switching on Amy 2 Modes io).
• It is impossible to add or delete Amy 2 Modes io to a motorised product if several channels are selected, which is
prevented when switched Off (refer to Channel selection on Amy 2 Modes io).
To add or delete Amy 2 Modes io, use the Somfy local io control point already paired
with the motorised product.
1] Position the motorised product at its half-way position.
2] On the individual control point already paired with the motorised product:
ð Press the PROG button until the motorised product moves up and down:
programming mode is activated.
3] On Amy 2 Modes io to be added or deleted:
ð Briefly press one channel selector button to select the channel: the green
LED on this button lights up.
ð Briefly press the PROG button: the motorised product moves up and
down and Amy 2 Modes io is added or deleted.
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Control mode selected
1
2
3
4
1
2
3
4
0.5 s
Low Power mode management
LPM activated
LPM activated
LPM activated
LPM activated
LPM deactivated
LPM deactivated
LPM deactivated
LPM deactivated
1]
2]
2 s
3]
EN
0.5 s
7
