EN
Briefly press only one button of the channel selector to select the motorised
product: the green LED of the selected channel lights up.
1] Press the Up or Down button to send the motorised product in the desired
position.
2] Briefly press my to stop the motorised product in the desired position.
3] Press and hold my until the activation of the motorised product to save or to
modify the favourite position (my).

3.4.Checking the battery level

When the battery level is low, the feedback LED on the front of Amy 2 Modes io dims
progressively during activation of the motorised product(s). When the battery is too
weak, the control point can no longer transmit radio orders, its operation is inhibited.
Battery status can be checked on TaHoma application, if Amy 2 Modes io has been added in TaHoma, and an alert may be
sent out if this feature is activated (Follow the instructions in TaHoma application).

3.5.Replacing the battery

DANGER
Read the Safety instructions document.
Explosion risk if the battery is replaced by an incorrect type.
1] Insert a flat screwdriver inside the hole at the bottom of the circular back
cover to easily eject the module from its support or, if the mounting plate and
its square frame are being used, manually remove the module from its
supports by pulling it towards you.
2] On the back of the module, remove first side of the battery cover by pushing
on the clip. Then pulling on the middle part of the battery cover to release the
first side of the cover. Push on the second clip to completely release the
cover.
3] Remove the battery cover.
4] Insert a CR2032 battery (3 V) with the (+) polarity side visible (on top), Slide it
and push to engage on the right side of the battery contact. Then insert the
stops of the cover on the bottom.
CAUTION
• Ensure you comply with the polarity.
• The power supply terminals must not be short-circuited.
5] Press on the top of the cover to engage the clips.
6] Clip the module onto the circular back cover or onto the square frame and
clip the square frame assembly onto the mounting plate again.
14
1]
2]
3]
1]
2]
3]
4]
5]
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Amy 2 Modes io
5 s
