Mode Selection - SOMFY Amy 2 Modes io Instructions Manual

EN

2.2.Mode selection

▪ The Mode button is used to choose a control mode adapted to the type of
motorised product being controlled (refer to Use and Maintenance for the
different ergonomics depending on the mode). 4 control modes are available:
◦ Mode 1: to control roller shutters, awnings, screens, windows, garage
doors, and gates.
◦ Mode 2: to control lighting and heating (on/off and dimming).
◦ Mode 3: to control external venetian blinds and roller shutters with
adjustable slats.
◦ Mode 4: to control internal venetian blinds.
▪ The Mode button is also used to deactivate or activate the Low Power Mode
(LPM) depending on the type of motorised products being controlled. The Low
Power Mode has to be activated if Amy 2 Modes io is associated with
autonomous drives or low consumption drives (compatible only with Somfy
autonomous products).
The choice of control mode and Low Power mode can be personalized for each
channel.
NOTICE
It is impossible to select a mode if several channels are selected (refer to Channel
selection on Amy 2 Modes io).
NOTICE
• By default, mode 1 is selected on Amy 2 Modes io.
• By default, the Low Power Mode is activated on Amy 2 Modes io.
• Deactivating the Low Power Mode increases the autonomy of Amy 2 Modes io and reduces radio communication
and any associated interference.
1] To check which mode is selected:
Press the channel selector to select the channel to be checked. Only one channel can be checked at a time.
Press and hold the Mode button (more than 2 seconds) to see the color and number
of the settings feedback LED flashes corresponding to the currently selected mode.
LED color and number of flashes
Green LED blinks 1 time
blinks 2 times
blinks 3 times
blinks 4 times
Red LED blinks 1 time
blinks 2 times
blinks 3 times
blinks 4 times
6
>2 s
Control mode
selected
1
2
3
4
1
2
3
4
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Amy 2 Modes io
Low Power mode
management
LPM activated
LPM deactivated
