Supermicro MicroBlade MBI-311C-1C2 User Manual page 11

Hide thumbs

Advertisement

Top view
Chipset
BMC Password
Sticker
M.2 Slot
Service/Asset Tag
Figure 1-3. Components Labeled (MBI-311C-1T2N model shown)
DIMM Slots
CPU and Heatsink
SATADOM
M.2 Slot
Add-on Module
Storage Drives
Latch Lever
11
Chapter 1: Introduction
