Control Panel - Supermicro MicroBlade MBI-311C-1C2 User Manual

Control Panel

Power Power LED
Feature State
Power button
Green
Power LED Amber steady
Amber blinking
Blue steady
KVM/UID LED
Blue blinking
Green blinking
NIC LED
Amber blinking
System Fail
Red
LED
KVM/UID LED
Figure 1-2. Control Panel
Control Panel Features
Description
The main power switch applies or removes primary power from the power
supply to the server but maintains standby power.
Power on
Power off
Before the BMC is ready, blinks until every node is ready
Indicates that KVM has been initialized
Unit Identifier indicator (The UID function is activated with a management
program.)
Indicates traffic (Tx and RX data) on the LAN connection to this blade
module
Indicates traffic over the network (when present in the system)
Indicates a fatal error. This may be a memory error, a VGA error or any
other fatal error that prevents the operating system from booting.
10
Chapter 1: Introduction
NIC LED System Fail LED
