1.1 Overview
The MBI-311C-(1C2/1T2N) blade is a compact, self-contained server that connects into a
pre-cabled enclosure that provides power, cooling, management and networking functions. A
Supermicro 6U Microblade enclosure can hold 20 blades. Each blade contains one computing
node. This system inherits Intel IT's disaggregated design architecture and provides significant
refresh savings.
In this manual, "blade" or "blade unit" refers to a single blade, and "blade enclosure" is the
chassis that houses the blades, power supplies and other modules. "Blade system" refers to
the enclosure, blades units, and various management and networking modules.
System
MBI-311C-1C2 SAS/SATA hybrid ports
MBI-311C-1T2N SATA/NVMe hybrid ports
Motherboard
B4SC1-CPU
Single Intel Xeon E-2400 Series processor in socket LGA 1700 with up to 8 cores and
Processor
95 W TDP
Up to 128GB of DDR5 ECC UDIMM memory with speeds of up to 4800 MT/s in four
Memory
memory slots; DIMM Size: Up to 128GB
Two fixed internal 2.5" drive positions:
MBI-311C-1C2, two U.2 SAS/SATA
MBI-311C-1T2N, two U.2 SATA/NVMe up to 15 mm
Storage Drives
M.2 SSDs:
MBI-311C-1C2, one SATA/NVMe PCIe 4.0 x4, form factor: 2280/22110, M-Key
MBI-311C-1T2N, one SATA/NVMe PCIe 4.0 x4, form factor: 2280/22110, M-Key and
LAN:
I/O Ports
MBI-311C-1C2, two 1 GbE, One dedicated BMC port
MBI-311C-1T2N, two 10 GbE, One dedicated BMC port
System Cooling
One air shroud, CPU heatsink
Form Factor
3U height; 1.2" x 4.94" x 23.2" (depth) (30.5 x 125.5 x 589.3 mm)
Eligible Enclosures
MBE-620E-830/630/430/822/622/422
Chapter 1
Introduction
Models
Storage Types
System Overview
additional M.2 slot, NVMe, PCIe 4.0 x4, form factor: 2280/22110
Add-on Module
AOM-BPNIO-MSC
AOM-BPNIO-MSH2
8
