Altronix TROVE T1KE3F4V Installation Manual
Altronix TROVE T1KE3F4V Installation Manual

Altronix TROVE T1KE3F4V Installation Manual

Kisi kits

Advertisement

Quick Links

Access & Power Integration
Altronix/Kisi Kits
Altronix/Kisi Kits
Models Include:
Models Include:
T1KE3F4V
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TDR1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
T1KE3F8V
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TDR1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- Two (2) ACM4 - Fused Access Power Controllers
T2KE33F16V
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TDR2 backplane
- Two (2) eFlow6NBV - Power Supply/Charger
- Two (2) ACM8 - Fused Access Power Controllers
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 102924
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1KE3F4DV
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TDR1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T1KE3F8DV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TDR1 backplane
- One (1) eFlow6NBV - Power Supply/Charger
- Two (2) ACM4CB - PTC Access Power Controllers
T2KE33F16DV
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TDR2 backplane
- Two (2) eFlow6NBV - Power Supply/Charger
- Two (2) ACM8CB - PTC Access Power Controllers
More than just power.™

Advertisement

loading
Need help?

Need help?

Do you have a question about the TROVE T1KE3F4V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altronix TROVE T1KE3F4V

  • Page 1 Access & Power Integration Altronix/Kisi Kits Altronix/Kisi Kits Models Include: Models Include: T1KE3F4V T1KE3F4DV 4 Door Kit with Fused Outputs 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TDR1 backplane...
  • Page 2 Overview: Altronix Trove Kisi kits are pre-assembled and consist of Trove1DR1 or Trove2DR2 enclosure/backplane with factory installed Altronix power supply/charger(s) and sub-assemblies. Trove Kisi kits also accommodates up to four (4) Kisi Pro Controllers for up to sixteen (16) doors in a single enclosure.
  • Page 3 Pem Mounting Pro Controller Fig. 2 - T1KE3F4(D)V Configuration TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix ACM4(CB) LED1 LED2 LED3 LED4 NC C NO COM NC C NO COM NC C NO COM NC C NO COM...
  • Page 4 Please make sure that they are mounted correctly, as shown in Fig. 3 below. 3. Fasten TDR1 backplane to Trove1 enclosure utilizing hardware (provided). Access Controller Position Chart for the Following Models: Kisi Pem Mounting Pro Controller Fig. 3 - T1KE3F8(D)V Configuration Altronix ACM4(CB) Altronix Altronix eFlow6NBV eFlow6NB TRIGGER INPUT...
  • Page 5 Access Controller Position Chart for the Following Models: Kisi Pem Mounting Pro Controller Fig. 4 - T2KE33F16(D)V Configuration OFF - 24V ON - 12V Altronix eFlow6NB Altronix eFlow6NBV AC DC NC C NO NC C NO TRIGGER +AUX- AC FAIL...
  • Page 6 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
  • Page 7 T1KE3F4(D)V and T1KE3F8(D)V Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6”...
  • Page 8 5.25” (133.4mm) 7.00” (177.8mm) 5.25” (133.4mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...

This manual is also suitable for:

Trove t1ke3f4dvTrove t1ke3f8vTrove t1ke3f8dvTrove t2ke33f16vTrove t2ke33f16dvTrove t1ke3f4 ... Show all
