- Page 1 HULALA SBHM0814 ITEM NO. NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/25...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
- Page 3 2PERSONEN 03/25...
- Page 4 PARTS LIST 04/25...
- Page 5 PARTS LIST 05/25...
- Page 6 HARDWARE LIST Ø 3.5*35mm*7 Ø3*14mm*6 Ø3.5*14m*7 Ø1/4*1/2 Ø1/4*1-1/4 Ø1/4 Ø1/4 TOOL LIST HARDWARE SPARE LIST 06/25...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-1 1.Use screw #16 to attach the weight parts R to bottom panel B, tighten screws with screwdriver #18. #16x12 Front Back 07/25...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-2 1.picture shows.Use bolt #3 to attach rebound device #12 to top panel A ， tighten bolts with screwdriver #18. #3x16 #12x4 08/25...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert side panel (C ＆ D&E) into top panel (A),make sure all holes aligned and then tighten it with allen key #17 as picture show. C&D C&D Back Front 09/25...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert bottom panel (B) into the corresponding hole of preassembled step 3 ， make sure all holes aligned and use allen key #17 to tighten it as picture show. C&D C&D 10/25...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-5 Open the back panel (F),insert back panel (F) into the groove of preassembled step 4,make sure all holes aligned and use screw #2 to attach them，tighten screw #2 with screwdriver #2X24 11/25...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-6 1.Aligned part (M&N&L) with leg (P&O) ,make sure all holes aligned and use bolt #4 &spring washer #7 &plat washer #8 to attach them ， tighten screw #4 with allen key #17.then use screw 4 and (washer 7 and spring washer 8) to connect O&Q and P&Q.
- Page 13 ASSEMBLY INSTRUCTIONS STEP-7 1.Insert leg (L&N&O&P) into the preassembled step 5 ， make sure all holes aligned and then use bolt #5 &spring washer #7 &plat washer #8 to attach them ， tighten screw #5 with allen key #17 . Do not fully tighten bolts until all bolts are in position!!! 13/25...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-8 1.Attention:After installation, adjust the adjustable leveler to keepthe cabinet balanced . Attention: After installation, adjust the adjustable leveler to keep the cabinet balanced . 14/25...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-9 Insert shelf holder #9 into the corresponding hole of panel (C)&(D)&(E) and then attach panel (G) to it. Shelf holder can be adjusted up or down 15/25...
- Page 16 ASSEMBLY INSTRUCTIONS STEP- 1.Use screw #1 to attach hinge #14 to door (H)&(K),tighten screw #1 with screwdriver #18 . 2.Use screw #1 to attach hinge #15 to door (I)&(J),tighten screw #1 with screwdriver #18 . When installing hinge ， please pay attention to distinguish the category of hinge 16/25...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Use screw #1 to attach left door (H) and right door (K) to pre-assemble unit at step 9 ,tighten screw with screwdriver #18. H&K C&E H&K 17/25...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Use screw #1 to attach middle door (I) to pre-assemble unit at step 11 ,tighten screw with screwdriver #18. 18/25...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-13 1.Use screw #1 to attach middle door (J) to pre-assemble unit at step 12 ,tighten screw with screwdriver #18. 19/25...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-14 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 20/25...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-15 Attention: If the door looks over out or over in,you can adjust the head rebounder as image. H＆ I 21/25...
- Page 22 ASSEMBLY INSTRUCTIONS #13 x2 STEP-16 to attach part #13 to back panel (F),tighten screw #1 with Use screw screwdriver #18 . #1x4 22/25...
- Page 23 ASSEMBLY INSTRUCTIONS #10 x4 STEP-17 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part #13 on the back of panel (F); Drill and insert the expandable screw by hammer. Assemble the part #13 to the wall. Align the hole in the part #13 with the expandable screw #10 , use screw #6 to attach it and tighten by screwdriver #18.
- Page 24 ASSEMBLY INSTRUCTIONS #11 x2 STEP-18 Let the plastic belt #11 pass through the both part #13 and pull tightly. #11x2 #11x2 24/25...
- Page 25 WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
