OPERATING INSTRUCTIONS
1004771-00 / us / kn / 05.2008
Sunrise 420 Turbo Power

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sunrise 420 Turbo Power and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ergoline Sunrise 420 Turbo Power

Summary of Contents for ergoline Sunrise 420 Turbo Power

  • Page 1 OPERATING INSTRUCTIONS 1004771-00 / us / kn / 05.2008 Sunrise 420 Turbo Power...
  • Page 2 Identify your tanning system For contact with Customer Services, please write down the device number of your tanning system. Global Service USA A Div of JK Products & Services, Inc. #1 Walter Kratz Drive Jonesboro, AR 72401 800-445-0624 870-935-9046 e-mail: support@jkamerica.com http://support.jkamerica.com...
  • Page 3 Skin types Skin types For the recommended exposure schedule see page 4. Skin type I (Sensitive): Invariably gets sunburn, accepts little natural sunlight and does not tan. Skin type II (Fair): This is the individual that usually burns easily and severely, tans minimal- ly or lightly and peels.
  • Page 4 Tanning times Note: Description of skin types see Page 3. “This product is in conformity with performance standards for sunlamp products under CFR21 Part 1040.”...
  • Page 5 Table of contents General safety instructions and information Description Operation Maintenance Technical data / appendix Index...
  • Page 6 Dear Customer, The Ergoline device you have purchased is a technically advanced and • Read and observe the information in this instruction manual. This will powerful product. Your device was manufactured with the greatest care enable you to prevent accidents and provide you with a reliable de- and precision.
  • Page 7 Table of contents Skin types ..........3 Operation Tanning times.
  • Page 8 Table of contents Technical data Connected load, power and noise level......62 Rated power, activation and power levels of the UV lamps..63 Installed lamps.
  • Page 9 Important safety notes Safety notices Caution notices, damage to property: Caution! Description of warning signs The word “Caution” with this label points out that danger for Danger notices, damage to persons: devices, materials and the environment can be expected here. Type and source of danger, e.g.
  • Page 10 Important safety notes Instructions pertaining to a risk of fire, electric shock, or injury DANGER – High voltage! WARNING – ultraviolet radiation! Follow instructions! You can be killed or injured by an electric shock! Failure to use protective eyewear may result in severe burns or other eye injury.
  • Page 11 Important safety notes – Repeated exposure may cause premature aging of the WARNING – risk of infection! skin and skin cancer. Infections can be transferred through skin contact. – Medications or cosmetics applied to the skin, may in- WARNING! WARNING! All items/equipment components, with which the user can crease sensitivity to ultraviolet light.
  • Page 12 Important safety notes Instructions pertaining to a risk of damage to the Note: machine Occasionally, persons using the tanning system will experi- ence a slight reddening of the skin – usually in small patch- CAUTION – danger of overheating! es – after the second or third session. This redness is often Danger of overheating by obstruction of the air routing.
  • Page 13 Information for the studio operator Meaning of symbols Inform Customer Services Display of tanning time Ergoline key Display of run-on time (fan run-on) Fault display (example), Do not touch, hot surface! see separate manual Low-pressure lamp(s) Display when adjusting the volume...
  • Page 14 Information for the studio operator Loudspeaker Visual inspection Headphone connection Filter/filter mat Caution, safety switch! Filter and filter mats must not be damp. Two persons are required for this work step. Continuation of work steps on next page Unscrew/release screw End of work step Tighten/lock screw Cleaning...
  • Page 15 Information for the studio operator Intended use Obligations of the studio operator • As the operator you are responsible for informing users on possible The tanning system is intended exclusively for cosmetic tanning of the risks during tanning. human skin. •...
  • Page 16 Audio-CDs, MCs, audio-DVDs etc., on your premises and/ or play music via the “MP3-music-modules” which are provided in the professional sunbeds in the Ergoline range, if you have acquired the nec- essary stage rights Copy protected audio CDs, MCs, audio DVDs etc, as well as the tracks on such sound storage media should not be converted to MP3 format and/or stored on HDD, audio CDs, MCs, audio DVDs etc.
  • Page 17 Disposal of recyclable materials The device has been produced of recyclable materials. When being scrapped later, the device must be disposed of properly. Sun Ergoline will provide you with information on the content or potential hazards of the materials used.
  • Page 18 Equipment Depending on the model, each device is equipped differently. This instruction manual covers all standard and optional components/ functions to be taken into consideration during operation and/or mainte- nance. The control panel also differs according to the various equipment: you only can choose those functions that are part of the device’s equipment.
  • Page 19 Description 1. Adjustable feet 2. Base plate 3. Floor mat (silicone) 4. UV low-pressure lamps 5. Operating panel, headphone connection 6. Handles 7. Loudspeaker (optional) 8. Fans (body cooling) 9. Interior lighting (LED) 10. Door pad 11. Accent lighting 12. Exhaust air (body cooling) 13.
  • Page 20 Accessories Stereo-Sound 7. Audio-system with Voice Guide, 2 loudspeakers 3D-Sound 7. Audio-system with Voice Guide 7.1. Headphone connection 7.2. MP3-connection Some accessory parts are taken into account in the maintenance schedule beginning on page 49 and in the spare parts section from page 66. However this does not automatically mean that your device is fitted with this equipment.
  • Page 21 Operation Mandatory reading Always read and follow all instructions for proper usage prior to allow Note: anybody using a tanning system. The operating instructions included When describing the operation, the tanning system is with this device must always be followed to prevent possible injuries or sometimes shown with the door open.
  • Page 22 Operation overview see separate instructions “Presettings”, Order no. 1001971...
  • Page 23 Operation / Navigation The unit is operated with the navigation ring. Switch tanning on and off, pause. Select device function (go to pictogram) Select sub-function (if available) Change setting Pictograms of available functions are illuminated in default mode after starting up the sunbed. After selecting a function, the corresponding pic- togram and the navigation ring flash for a short time.
  • Page 24 Tanning Use the sunbed – but use it properly! Are medications and the sunbed compatible? It is known that some medications increase the skin's sensitivity to UV A few things need to be noted to get maximum enjoyment from a sunbed. light.
  • Page 25 Tanning Start of tanning The device is started automatically with an internal or external timer. Note: Timer instructions: see separate manual Preparation time Before the UV lamps turn on, you have a few minutes to prepare yourself. During the preparation time you can switch on the UV lamps at any time by touching the START/STOP button.
  • Page 26 Tanning Danger! Sunburn and skin damage will occur if the distance between the UV lamps and the surface of your skin is insufficient. DANGER! – Stand straightly and centrally in the unit during tanning. – Use the handles to make holding up your arms easier so that your body gets an even tan.
  • Page 27 Tanning Closing the door Settings on start-up...
  • Page 28 Tanning Interrupt or end tanning session The tanning session ends automatically after the preset time has run down. The internal fan continues to run for approx. three (3) minutes to sufficiently cool the device. – To interrupt a tanning session, touch START/STOP anytime during a session.
  • Page 29 Regulating body cooling – Touch to select body cooling (symbol is illuminated, the navigation ring flashes). – While the ring flashes, touch the plus or minus button to change the intensity of the air stream.
  • Page 30 Regulating body cooling...
  • Page 31 Connecting an MP3 player Studio customers can connect their own MP3 player to the device when the “Audio System” accessory is available. Jack plug (Mat.-Nr. 1001855-..) provided for use by the studio oper- ator (1.5 m / 2 x 3.5 mm stereo jack plug). MP3 player connection: refer to the manufacturer’s documentation.
  • Page 32 Connecting an MP3 player Caution! Heat can damage your MP3 player – Do not place the MP3 player on the irradiated area. Cable may be torn off, connectors may be damaged. – Do not pull on cable when unplugging MP3 player.
  • Page 33 Voice Guide Voice Guide gives acoustic guidance when operating the device and is only available in conjunction with the audio system. Voice Guide is activated by default during both stand-by and a tanning session. STOP 11026 / 0...
  • Page 34 Voice Guide START...
  • Page 35 Listening to Info texts General information about the sunbed.
  • Page 36 Listening to Info texts Example:...
  • Page 37 Selecting the audio system Intern (internal): SD card “music” Extern (external): externally connected systems (e.g. CD-player) MP 3: MP3 player...
  • Page 38 Selecting the audio system Choosing a track (internal)
  • Page 39 Selecting the audio system...
  • Page 40 Adjusting the volume and switching-off the audio system Risk of hearing loss! – With time, the human ear becomes accustomed to high sound levels. WARNING! – The higher you adjust the volume, the quicker the hear- ing can be damaged. –...
  • Page 41 Adjusting the volume and switching-off the audio system Minimum...
  • Page 42 Running time of accent lights The accent lights are automatically switched on at the end of the tanning session after the Stand-by set operating time and are switched off again at the beginning of the next tannings session. The running time of the accent lights in the Standby mode can be changed with the preset- tings –...
  • Page 43 Safety information for maintenance and care Extreme danger! High voltage! CAUTION! During maintenance work there is a risk of touching live Only use genuine spare parts of the same type! parts and receiving a fatal electric shock. The use of other parts may limit or void your manufacturer’s DANGER! warranty! –...
  • Page 44 Safety information for maintenance and care Power Off device and secure against being switched on again A prohibition sign with the text: Extreme danger! “Work in progress!” If work is to be performed on the devices, • “Place: ......” they must be powered off. That means that DANGER! all live lines must be switched off.
  • Page 45 Safety information for maintenance and care Malfunctions The display shows error codes to make it easier to localize the cause of the problem. • If a malfunction occurs, the error code flashes in the display. • If several malfunctions occur, the error messages are displayed alter- nately.
  • Page 46 Maintenance overview see separate instructions “Presettings”, Order no. 1001971...
  • Page 47 Cleaning Acrylic glass surfaces WARNING – risk of infection! Infections can be transferred through skin contact. CAUTION! All items/equipment components, with which the user can Do not rub with a dry cloth – danger of scratching! WARNING! come into contact during tanning, must be disinfected after For fast, hygienic proper cleaning of acrylic glass surfaces, every tanning session: use a specially developed fast disinfectant cleaner.
  • Page 48 Cleaning Plastic surfaces Cleaning lamps For cleaning the other plastic surfaces, it is best to use warm water and UV low pressure lamps: Clean with water only (damp a leather cloth. Never use aggressive cleaning agents containing alcohol cloth) or essential oils. These may lead, in the long run, to damage not covered by the warranty.
  • Page 49 Cleaning and maintenance intervals After each tanning  ☞ 47 Schmerler 2255  ☞ 47 Ergoline 84592  ☞ 47  ☞ 47 Confirm cleaning by touching START/STOP (when the follow-up time of the fan in the device has finished).
  • Page 50 Cleaning and maintenance intervals  ☞ 47 Acrylic glass  ☞ 47  Air intake openings Fire hazard! Dust particles are combustible! Regularly remove dust particles in the air intake area. – Use a vacuum cleaner to prevent dust particles getting inside the unit.
  • Page 51 Cleaning and maintenance intervals 500 h ☞ 53 ☞ 55 ☞ 55 1000 h a) b) ☞ 53, 55 ☞ 60...
  • Page 52 Relamping / maintenance instructions It is imperative that you, the owner and/or operator, check all compo- – Before replacing lamps or other spare parts, wait until nents for any signs of wear which may occur through normal use. lamps and metal parts of the device have cooled down sufficiently.
  • Page 53 Cleaning/replacing UV low-pressure lamps in the door 03108 / 0 Power Off!
  • Page 54 Cleaning/replacing UV low-pressure lamps in the door Caution! Soiling on the panes is burned in by the hot lamps and results in the long term in unserviceable panes. – Remove fingerprints and other soiling carefully. 03099 / 0...
  • Page 55 Cleaning/replacing UV low-pressure lamps in the side panels Power Off! Note: The acrylic glass panels may be dam- aged at the side walls and the operat- ing unit. – Observe sequence: First, remove the left acrylic glass panel, then the right. –...
  • Page 56 Cleaning/replacing UV low-pressure lamps in the side panels 03108 / 0 10649 / 0...
  • Page 57 Cleaning/replacing UV low-pressure lamps in the side panels Attention! Soiling on the panes is burned in by the hot lamps and results in the long term in unserviceable panes. – Remove fingerprints and other soiling carefully. 03099 / 0...
  • Page 58 Cleaning/replacing UV low-pressure lamps in the side panels 03099 / 0...
  • Page 59 Cleaning/replacing UV low-pressure lamps in the side panels Attention! Soiling on the panes is burned in by the hot lamps and results in the long term in unserviceable panes. – Remove fingerprints and other soiling carefully.
  • Page 60 Cleaning/replacing accent lights in the door 03350 / 0 Power Off!
  • Page 61 Cleaning/replacing accent lights in the door 03099 / 0...
  • Page 62 Connected load, power and noise level Sunrise 420 Model: Turbo Power Powerinput 3-pole Powerinput 1-pole Rated power con- (max. 50 amp) (max. 90 amp) 10,200 W 230V AC 60 Hz 230V AC 60 Hz sumption: Rated frequency: 60 Hz Rated voltage: 230 V 40 amp 3-pole or Fuse rating:...
  • Page 63 Rated power, activation and power levels of the UV lamps Rated power Activation / power levels Sunrise 420 Turbo Power 200 W 200 W / – 200 W 200 W / – 200 W 200 W / –...
  • Page 64 Installed lamps UV lamps, starters Order No. and lamp name Sunrise 420 Turbo Power Low pressure lamps 1005565-.. Ergoline Turbo Power 200 W 1005565-.. Ergoline Turbo Power 200 W 1005565-.. Ergoline Turbo Power 200 W Starter a) b) c) 10002-.. Starter S12...
  • Page 65 Installed lamps Accent lights Standard lamps blue 58 W 12063-.. Starter 10047-..
  • Page 66 Spare parts and accessories Acrylic glass, fan  1501829-.. Ergoline 84592-.. Schmerler 2255  1502469-..  1502470-..
  • Page 67 Dimensions 54 13/16 in TK = 94 1/2 in 1,392 mm TK = 2,400 mm B1 = 34 1/8 in TK1 = 34 5/8 in B1 = 866 mm TK1 = 880 mm B4 = 6 9/16 in TK2 = 11 13/16 in B4 = 166 mm...
  • Page 68 Manual can lead to serious system malfunctions. Data for air supply and extraction planning can be found in the Ergoline Planning manual (www.sunergoline.de). You can also ask for this data from your sales agent or customer service (see Page 2).
  • Page 69 JK-Products, Inc. – Limited Warranty JK-Products, Inc. warrants its products to be free from defects in materi- This warranty is extended to the individual or legal entity, whose name als and workmanship under intended normal use as described in the appears on the warranty registration card filed with Global Service USA, unit's Operation and Instruction Manual, for a period of three (3) years or whose name appears on the original sale document and may not be...
  • Page 70 JK-Products, Inc. – Limited Warranty Limited Acrylic Warranty JK Products, Inc. warrants its acrylic sheets to be free from defects in ma- Global Service USA terial and workmanship, under intended normal use, for a period of one A Div of JK Products & Services, Inc. (1) year from date of sale of the tanning bed.
  • Page 71 JK-Products, Inc. – Limited Warranty Warranty Claims Each dealer/distributor has their own internal procedure for handling Warranty Claims and credits. Policy & Procedures NOTE: JK-Products, Inc., the manufacturer, does not involve itself 1. When to file a Warranty Claim: in the direct handling of a Warranty Claim except where mit- In the event that your tanning system is not functioning properly under in- igating circumstances apply and where required by law.
  • Page 72 JK-Products, Inc. – Limited Warranty Limited Lifetime Warranty There are no warranties which extend beyond the description on the face hereof. There is no express or implied warranty of fitness or merchant- Global Service USA warrants specific individual components of the tan- ability.
  • Page 73 Index Door, accent lights ........60 Maintenance overview.........46 Door, replacing the UV lamps ..... 53 Make-up ............24 Accent lights ..........65 Malfunctions ..........45 Accent lights, replace........60 Medication ...........24 Accessories ..........20 Ending tanning session....... 28 MP3 music, product information....16 Acrylic glass panel Environmental protection ......
  • Page 74 Index Running time of accent lighting....42 Ventilation data, see Planning Manual..68 Voice Guide..........33 Safety information, maintenance ....52 Volume............40 Selecting audio system....... 37 Showering........... 24 Side panels Replacing the UV lamps ....55 Skin sensitivity ..........24 Skin types .............
